Loop-O9500-R-24FXO-M-G
24-channel FXO plug-in card with 600/900
Impedance, Battery Reverse, Loop Start and
[Metering Pulse].
Loop- O9500-R-24FXO-GS-G
24-channel FXO plug-in card with 600/900
Impedance, Battery Reverse, Loop Start and
[Ground Start].
Loop- O9500-R-24FXO-GM-G
24-channel FXO plug-in card with 600/900
Impedance, Battery Reverse, Loop Start,
[Ground Start] and [Metering Pulse].
Feature Activation License
Loop-O9500-R-3M13
Feature Activation License for O9500-R 3TE3 module
to support M13/Mx3 function for T3 interface only
· Use with 3TE3 HS tributary
module
Loop-O9500-R-ERING
Feature Activation License for O9500-R controller
module to support framed E1 PDH-Ring function
· Use with 4E1 or FOM LS tributary
modules
Loop-O9500-R-TRING
Feature Activation License for O9500-R controller
module to support framed T1 PDH-Ring function
· Use with 4T1 LS tributary modules
Accessories
SFP Optical Modules
Please place your order using the 5-digit alphanumeric codes listed in the separate SFP Optical Module Brochure.
User’s Manual
Loop-O9500-R-UMA
Optional, paper copy of User Manual. A CD version of the manual is already included
as standard package.
Power Modules
Loop-O9500-R-SD48-G
Single power module -48Vdc
· For redundancy purposes, order 2
single DC.
Loop-O9500-R-SD48/125-G
Single power module (300W) Input,
48Vdc/125Vdc (36 to 140Vdc)
· For redundancy purposes, order 2
single DC.
Loop-O9500-R-SD125/250-G
Single power module (300W)
Input 125Vdc/250Vdc (100 to 260Vdc)
· For redundancy purposes, order 2
single DC.
Power Adaptor (All power adaptor are RoHS compliant)
Loop-ACC-APA-240-G
240 Watt, AC (100 to 120 Vac, 5.0A/200 to 240
Vac, 2.5A auto sensing) to DC (-48 Vdc, 5A)
adaptor for USA
· This power adaptor is only for
Loop-O9500-R-SD48.
Loop-ACC-APE-240-G
240 Watt, AC (100 to 120 Vac, 5.0A/200 to 240
Vac, 2.5A auto sensing) to DC (-48 Vdc, 5A)
adaptor for Europe
Loop-ACC-APU-240-G
240 Watt, AC (100 to 120 Vac, 5.0A/200 to 240
Vac, 2.5A auto sensing) to DC (-48 Vdc, 5A)
adaptor for UK
FXO BOX
Loop-ACC-FXOBOX
Support FXO Interface Feed
Order wire phone is an option for CBA board
Loop-O9500-R-OW-USA-G
Ethernet Order Wire phone (using VoIP
technology) with America power plug
Loop-O9500-R-OW-EU-G
Ethernet Order Wire phone (using VoIP
technology) with Europe power plug
SIP Proxy Server
Loop-O9500-R-SIP
SIP Proxy Server Basic Software
Note: One SIP Proxy Server License supports up
to 25 phone lines. Multiple licenses must be
purchased if the number of phone lines exceeds
25.
· Customer must provide a MAC
address so that a license key can
be generated to operate the
software at that address.
Mounting Ear
19”/23” ear mounts
A pair of 19”/23” ear mounts is supplied as part of standard package.
Note: For other sizes, please contact your nearest Loop sales representative.
