Lorentz PS2-150 - 7.6.1 Terminal Descriptions

Table 3: PS2 Controller dimensions for installation
Dimension in mm [in]
Weight in kg [lbs]W1 W2 W3 H1 H2 H3 D1
207 170 164 352 333 300 124 4.5
[8.15] [6.69] [6.46] [13.86] [13.11] [11.81] [4.88] [9.9]
Figure 3: PS2 Controller dimensions for installation
W1
W3
H3
H1
H2
D1W2
20 Controller Installation
