Lotek Biotracker Receiver User’s Manual Page 13
Storing frequencies to memory (channels)
The receiver has 256 memory channels to which you can save frequencies.
Initial Conditions
The receiver needs to be in Frequency Mode, and set to
the frequency you wish to store.
Step 1
Press to display the last used channel
on the top row.
Step 2
Use to select the channel in which you want to
store the frequency.
OR…
Enter the channel number from the numeric keypad then
Step 3
Press to save the frequency in the chosen channel.
The receiver will revert to Channel Mode with the stored
channel selected.
Software to enable channel frequencies to be uploaded via a serial or USB port from a PC
is available.
