I185 GB 06 15 LRX D01
12
ANALOG INPUTS
Resolution Base unit: 12 bit
Voltage Range acceptable Base unit: Analog input: 0-10VDC voltage,
12VDC/24VDC when used as discrete input
Input Signal ”OFF” Threshold <2.5VDC (as 12VDC discrete input); <5VDC (as 24VDC discrete input)
Input Signal ”ON” Threshold >7.5VDC (as 12VDC discrete input); >9.8VDC (as 24VDC discrete input)
Insulation None
Short circuit protection Yes
Total number available Base unit: A01-A04
RELAY OUTPUTS
Contact material Ag Alloy
Current rating 8A
HP rating 1/3HP at 120V; 1/2HP at 250V
Maximum Load Resistive: 8A /point
Inductive: 4A /point
Maximum operating time 15ms (normal condition)
Life expectancy (rated load) 100,000 operations
Minimum load 16.7mA
TRANSISTOR OUTPUTS
PWM max. output frequency 1.0kHz (0.5ms on,0.5ms off)
Standard max. output frequency 100Hz
Voltage specification 10-28.8VDC
Current capacity 1A
Maximum Load Resistive: 0.5A/point
Inductive: 0.3A/point
Minimum Load 0.2mA
SPECIFICHE DEL PRODOTTO
Base modules
Order code Input Power Inputs Outputs Display and Keypad Max I/O
LRD12RD024 24VDC 6 digital of which 4 Relay √, Z01-Z04 12 + 24
2 digital/analog
LRD12TD024 24VDC 6 digital of which 4 Transistor √, Z01-Z04 12 + 24
2 digital/analog
LRD20RD012 12VDC 8 digital of which 8 Relay √, Z01-Z04 20 + 24
4 digital/analog
LRD20RD024 24VDC 8 digital of which 8 Relay √, Z01-Z04 20 + 24
4 digital/analog
LRD20RD024P1 24VDC 8 digital of which 8 Relay √, Z01-Z04 20 + 24
4 digital/analog
LRD10RA240 100-240VAC 6 digital 4 Relay √, Z01-Z04 10 + 24
LRD20RA240 100-240VAC 12 digital 8 Relay √, Z01-Z04 20 + 24
LRD12RA024 24VAC 8 digital 4 Relay √, Z01-Z04 12 + 24
LRD20RA024 24VAC 12 digital 8 Relay √, Z01-Z04 20 + 24
Expansion modules
LRE02AD024 24VDC –– 2 analog –– ––
LRE04AD024 24VDC 4 analog –– –– ––
LRE04PD024 24VDC 4 PT100 –– –– ––
LRE08RD024 24VDC 4 digital 4 Relay –– ––
LRE08TD024 24VDC 4 digital 4 Transistor –– ––
LRE08RA240 100-240VAC 4 digital 4 Relay –– ––
LRE08RA024 24VAC 4 digital 4 Relay –– ––
LREP00 24VDC Communications Module, RS485 ModBus RTU slave
Accessories
LRXC00 LRD Programming Cable, LRD Programming software for PC RS232 port
LRXC03 LRD Programming Cable, LRD Programming software for PC USB port
LRXM00 LRD program backup memory
If LRD module is with keypad and display, digital inputs Z01-Z04 (4 arrows keys) can be added to Max I/O table quantities. Those values refer
to digital I/O of base + expansion modules.
More information about Product Specifications to see “Chapter 7: Product Specifications”.
