Doc. AHIT101A0510.doc 10/02/2011 P. 15 / 18
CODE MENU MENU MIN MAX DEF WORDS ADDRESS
M06 Comunicazione Communication
P06.n.01 Indirizzo seriale nodo Serial node address 1 255 1 1
n6180H+ (n -1) * 80H
P06.n.02 Velocità seriale Serial speed 0 5 3 1
n6182H+ (n -1) * 80H
P06.n.03 Formato dati Data format 0 4 0 1
n6184H+ (n -1) * 80H
P06.n.04 Bit di stop Stop bits 0 1 0 1
n6186H+ (n -1) * 80H
P06.n.05 Protocollo Protocol 0 1 0 1
n6188H+ (n -1) * 80H
P06.n.06 Indirizzo IP IP address 0 255 0.0.0.0 2
n618AH+ (n -1) * 80H
P06.n.07 Subnet mask Subnet mask 0 255 0.0.0.0 2
n619AH+ (n -1) * 80H
P06.n.08 Porta IP IP port 0 9999 1001 1
n61AAH+ (n -1) * 80H
P06.n.09 Funzione Gateway Gateway function OFF ON ON
n61ACH+ (n -1) * 80H
M07 Soglie limite Limit thresholds
P07.n.01 Misura riferimento Reference measure 0 41 0 1
n6280H+ (n -1) * 80H
P07.n.02 Funzione Function 0 2 0 1
n6282H+ (n -1) * 80H
P07.n.03 Soglia superiore Upper threshold -9999 9999 0 1
n6284H+ (n -1) * 80H
P07.n.04 Moltiplicatore Multiplier 0 6 2 1
n6286H+ (n -1) * 80H
P07.n.05 Ritardo Delay 0 6000 0 1
n6288H+ (n -1) * 80H
P07.n.06 Soglia inferiore Lower threshold -9999 9999 0 1
n628AH+ (n -1) * 80H
P07.n.07 Moltiplicatore Multiplier 0 6 2 1
n628CH+ (n -1) * 80H
P07.n.08 Ritardo Delay 0 6000 0 1
n628EH+ (n -1) * 80H
P07.n .09 Stato di riposo Normal status 0 1 0 1
n6290H+ (n -1) * 80H
P07.n .10 Memoria Latch 0 1 0 1
n6292H+ (n -1) * 80H
M08 Allarmi Alarms
P08.n .01 Sorgente allarme Alarm source 0 3 0 1
n6680H + (n -1) * 80H
P08.n .02 Numero canale (x) Channel number (x) 1 8 1 1
n6682H + (n -1) * 80H
P08.n .03 Memoria Latch 0 1 0 1
n6684H + (n -1) * 80H
P08.n .04 Priorità Priority 0 1 0 1
n6686H + (n -1) * 80H
P08.n .05 Testo Text ALAn 8
n6688H + (n -1) * 80H
M09 Logica booleana Boolean Logic
P09.n .01 Operando 1 Operand 1 0 5 0 1
n6A80H + (n -1) * 80H
P09.n .02 Numero canale (x) Channel number (x) 1 8 1 1
n6A82H + (n -1) * 80H
P09.n .03 Operatore logico 1 Logic operator 1 0 6 0 1
n6A84H + (n -1) * 80H
P09.n .04 Operando 2 Operand 2 0 5 0 1
n6A86H + (n -1) * 80H
P09.n .05 Numero canale (x) Channel number (x) 1 8 1 1
n6A88H + (n -1) * 80H
P09.n .06 Operatore logico 2 Logic operator 2 0 6 0 1
n6A8AH + (n -1) * 80H
P09.n .07 Operando 3 Operand 3 0 5 0 1
n6A8CH + (n -1) * 80H
P09.n .08 Numero canale (x) Channel number (x) 1 8 1 1
n6A8EH + (n -1) * 80H
P09.n .09 Operatore logico 3 Logic operator 3 0 6 0 1
n6A90H + (n -1) * 80H
P09.n .10 Operando 4 Operand 4 0 5 0 1
n6A92H + (n -1) * 80H
P09.n .11 Numero canale (x) Channel number (x) 1 8 1 1
n6A94H + (n -1) * 80H
