Doc. AHIT101C0208.doc Date: 10/11/2009 P. 15 / 18
CODE MENU MENU MIN MAX DEF WORDS ADDRESS
DMG
210
DMG
300
DMG
700
DMG
800
M07 Coumunicazione Communication
P07.n.01 Indirizzo seriale nodo Serial node address 1 255 1 1
n5300H + (n -1) * 80H
● ● ● ●
P07.n.02 Velocità seriale Serial speed 0 5 3 1
n5302H + (n -1) * 80H
● ● ● ●
P07.n.03 Formato dati Data format 0 4 0 1
n5304H + (n -1) * 80H
● ● ● ●
P07.n.04 Bit di stop Stop bits 0 1 0 1
n5306H + (n -1) * 80H
● ● ● ●
P07.n.05 Protocollo Protocol 0 1 0 1
n5308H + (n -1) * 80H
● ● ● ●
P07.n.06 Indirizzo IP IP address 0 255 0.0.0.0 2
n530AH + (n -1) * 80H
● ● ● ●
P07.n.07 Subnet mask Subnet mask 0 255 0.0.0.0 2
n530CH + (n -1) * 80H
● ● ● ●
P07.n.08 Porta IP IP port 0 9999 1001 1
n530EH + (n -1) * 80H
● ● ● ●
M08 Soglie limite Limit thresholds
P08.n.01 Misura riferimento Reference measure 0 41 0 1
n5400H + (n -1) * 80H
● ● ●
P08.n.02 Funzione Function 0 2 0 1
n5402H + (n -1) * 80H
● ● ●
P08.n.03 Soglia superiore Upper threshold -9999 9999 0 1(signed)
n5404H + (n -1) * 80H
● ● ●
P08.n.04 Moltiplicatore Multiplier 0 6 2 1
n5406H + (n -1) * 80H
● ● ●
P08.n.05 Ritardo Delay 0 6000 0 1
n5408H + (n -1) * 80H
● ● ●
P08.n.06 Soglia inferiore Lower threshold -9999 9999 0 1(signed)
n540AH + (n -1) * 80H
● ● ●
P08.n.07 Moltiplicatore Multiplier 0 6 2 1
n540CH + (n -1) * 80H
● ● ●
P08.n.08 Ritardo Delay 0 6000 0 1
n540EH + (n -1) * 80H
● ● ●
P08.n .09 Stato di riposo Normal status 0 1 0 1
n5410H + (n -1) * 80H
● ● ●
P08.n .10 Memoria Latch 0 1 0 1
n5412H + (n -1) * 80H
● ● ●
M09 Allarmi Alarms
P09.n .01 Sorgente allarme Alarm source 0 3 0 1
n5800H + (n -1) * 80H
● ● ●
P09.n .02 Numero canale (x) Channel number (x) 1 8 1 1
n5802H + (n -1) * 80H
● ● ●
P09.n .03 Memoria Latch 0 1 0 1
n5804H + (n -1) * 80H
● ● ●
P09.n .04 Priorità Priority 0 1 0 1
n5806H + (n -1) * 80H
● ● ●
P09.n .05 Testo Text ALAn 8
n5808H + (n -1) * 80H
● ● ●
M10 Contatori Counters
P10.n .01 Sorgente conteggio Counter source 0 4 0 1
n5C00H + (n -1) * 80H
● ● ●
P10.n .02 Numero canale (x) Channel number (x) 1 8 1 1
n5C02H + (n -1) * 80H
● ● ●
P10.n .03 Moltiplicatore Multiplier 1 1000 1 1
n5C04H + (n -1) * 80H
● ● ●
P10.n .04 Divisore Divider 1 1000 1 1
n5C06H + (n -1) * 80H
● ● ●
P10.n .05
Descrizione del
contatore
Counter description CNTn 8
n5C08H + (n -1) * 80H
● ●
●
P10.n .06 Unità di misura Unit of measure Umn 3
n5C10H + (n -1) * 80H
● ● ●
M11 Impulsi energia Energy Pulse
P11.n .01 Misura sorgente Source measurement 0 5 0 1
n5E00H + (n -1) * 80H
● ● ●
P11. n.02 Unità conteggio Count unit 0 3 1 1
n5E02H + (n -1) * 80H
● ● ●
P11. n.03 Durata impulso Pulse duration 10 1000 100 1
n5E04H + (n -1) * 80H
● ● ●
M12 Logica booleana Boolean Logic
P12.n .01 Operando 1 Operand 1 0 5 0 1
n6080H + (n -1) * 80H
● ● ●
P12.n .02 Numero canale (x) Channel number (x) 1 8 1 1
n6082H+ (n -1) * 80H
● ● ●
P12.n .03 Operatore logico 1 Logic operator 1 0 6 0 1
n6084H + (n -1) * 80H
● ● ●
P12.n .04 Operando 2 Operand 2 0 5 0 1
n6086H + (n -1) * 80H
● ● ●
P12.n .05 Numero canale (x) Channel number (x) 1 8 1 1
n6088H + (n -1) * 80H
● ● ●
P12.n .06 Operatore logico 2 Logic operator 2 0 6 0 1
n608AH + (n -1) * 80H
● ● ●
P12.n .07 Operando 3 Operand 3 0 5 0 1
n608CH + (n -1) * 80H
● ● ●
P12.n .08 Numero canale (x) Channel number (x) 1 8 1 1
n608EH + (n -1) * 80H
● ● ●
P12.n .09 Operatore logico 3 Logic operator 3 0 6 0 1
n6090H + (n -1) * 80H
● ● ●
P12.n .10 Operando 4 Operand 4 0 5 0 1
n6092H + (n -1) * 80H
● ● ●
P12.n .11 Numero canale (x) Channel number (x) 1 8 1 1
n6094H + (n -1) * 80H
● ● ●
