Lovato DMG210 - Page 9

Doc. AHIT101C0208.doc Date: 10/11/2009 P. 9 / 18
TABELLA 2: TABLE 2:
MISURE FORNITE DAL PROTOCOLLO DI COMUNICAZIONE MEASURES SUPPLIED BY SERIAL COMMUNICATION PROTOCOL
(Utilizzabili con funzioni 03 e 04) (To be used with functions 03 and 04)
Indirizzo
Address
WORDS
MISURA
MEASURE
UNITA’
UNIT
FORMATO
FORMAT
DMG
210
DMG
300
DMG
700
DMG
800
MISURA ISTANTANEA MEASURE ISTANTANEOUS
0002H 2 Tensione Di Fase L1 L1 Phase Voltage V/100 Unsigned long
● ● ● ●
0004H 2 Tensione Di Fase L2 L2 Phase Voltage V/100 Unsigned long
● ● ● ●
0006H 2 Tensione Di Fase L3 L3 Phase Voltage V/100 Unsigned long
● ● ● ●
0008H 2 Corrente Di Fase L1 L1 Current A/10000 Unsigned long
● ● ● ●
000AH 2 Corrente Di Fase L2 L2 Current A/10000 Unsigned long
● ● ● ●
000CH 2 Corrente Di Fase L3 L3 Current A/10000 Unsigned long
● ● ● ●
000EH 2 Tensione L1-L2 L1-L2 Voltage V/100 Unsigned long
● ● ● ●
0010H 2 Tensione L2-L3 L2-L3 Voltage V/100 Unsigned long
● ● ● ●
0012H 2 Tensione L3-L1 L3-L1 Voltage V/100 Unsigned long
● ● ● ●
0014H 2 Potenza Attiva L1 L1 Active Power W/100
Signed long ● ● ● ●
0016H 2 Potenza Attiva L2 L2 Active Power W/100
Signed long ● ● ● ●
0018H 2 Potenza Attiva L3 L3 Active Power W/100
Signed long ● ● ● ●
001AH 2 Potenza Reattiva L1 L1 Reactive Power Var/100
Signed long ● ● ● ●
001CH 2 Potenza Reattiva L2 L2 Reactive Power Var/100
Signed long ● ● ● ●
001EH 2 Potenza Reattiva L3 L3 Reactive Power Var/100 Signed long
● ● ● ●
0020H 2 Potenza Apparente L1 L1 Apparent Power VA/100 Unsigned long
● ● ● ●
0022H 2 Potenza Apparente L2 L2 Apparent Power VA/100 Unsigned long
● ● ● ●
0024H 2 Potenza Apparente L3 L3 Apparent Power VA/100 Unsigned long
● ● ● ●
0026H 2 Fattore Di Potenza L1 L1 Power Factor /10000 Signed long
● ● ● ●
0028H 2 Fattore Di Potenza L2 L2 Power Factor /10000 Signed long
● ● ● ●
002AH 2 Fattore Di Potenza L3 L3 Power Factor /10000 Signed long
● ● ● ●
0032H 2 Frequenza Frequency
Hz/100 210
Hz/1000 300
Hz/1000 700
Hz/1000 800
Unsigned long ● ● ● ●
0034H 2 Tensione Di Fase Equivalente Eqv. Phase Voltage V/100 Unsigned long
● ● ● ●
0036H 2 Tensione Di Linea Equivalente Eqv. Phase-To-Phase Voltage V/100 Unsigned long
● ● ● ●
0038H 2 Corrente Equivalente Eqv. Current A/10000 Unsigned long
● ● ● ●
003AH 2 Potenza Attiva Equivalente Eqv. Active Power W/100 Signed long
● ● ● ●
003CH 2 Potenza Reattiva Equivalente Eqv. Reactive Power Var/100 Signed long
● ● ● ●
003EH 2 Potenza Apparente Equivalente Eqv. Apparent Power VA/100 Unsigned long
● ● ● ●
0040H 2 Fattore Di Potenza Equivalente Eqv Power Factor /10000 Signed long
● ● ● ●
0042H 2 Asimmetria Tensione Fase-Fase Asymmetriy Phase-Phase Voltage %/100 Unsigned long
● ● ● ●
0044H 2 Asimmetria Tensione Fase-Neutro Asymmetriy Phase-Neural Voltage %/100 Unsigned long
● ● ● ●
0046H 2 Asimmetrica Corrente di Neutro Asymmetriy Neutral Current %/100 Unsigned long
● ● ● ●
0048H 2 Corrente di Neutro Neutral Current A/10000 Unsigned long
● ● ● ●
0054H 2 Thd Tensione L1 Thd L1 Voltage %/100 Unsigned long
● ● ● ●
0056H 2 Thd Tensione L2 Thd L2 Voltage %/100 Unsigned long
● ● ● ●
0058H 2 Thd Tensione L3 Thd L3 Voltage %/100 Unsigned long
● ● ● ●
005AH 2 Thd Corrente L1 Thd L1 Current %/100 Unsigned long
● ● ● ●
005CH 2 Thd Corrente L2 Thd L2 Current %/100 Unsigned long
● ● ● ●
005EH 2 Thd Corrente L3 Thd L3 Current %/100 Unsigned long
● ● ● ●
0060H 2 Thd Tensione L1-2 Thd L1-2 Voltage %/100 Unsigned long
● ● ● ●
0062H 2 Thd Tensione L2-3 Thd L2-3 Voltage %/100 Unsigned long
● ● ● ●
0064H 2 Thd Tensione L3-1 Thd L3-1 Voltage %/100 Unsigned long
● ● ● ●
