Lovato DMG800 - Terminal Layout and Mechanical Dimensions; Terminal Positioning; Mechanical Dimensions

I272 I GB F E 07 11 31100125
41
DIMENSIONI MECCANICHE MECHANICAL DIMENSIONS DIMENSIONS D’ENCOMBREMENT DIMENSIONES MECÁNICAS
96
96
1953.2
99.5
61.5
92
92
DISPOSIZIONE MORSETTI TERMINALS POSITION DISPOSITION DES BORNES DISPOSICIÓN TERMINALES
