Humidity Conditions: 0 to 90% up to 40°C non-condensing, 10 to 50% at 55°C
non-condensing.
Memory Backup: Nonvolatile memory. No batteries required.
Control Output Ratings:
SSR: 2.0 A combined outputs A & B @ 240 VAC at 25°C (77°F).
Derates to 1.0 A @ 55°C (130°F).
Relay: SPST, 3 A @ 240 VAC resistive; 1.5A @ 240 VAC inductive; Pilot
duty rating 240 VA, 2 A @ 120 VAC or 1 A 240 VAC.
Alarm Relay: SPST, 3 A @ 240 VAC resistive; 1/10 HP @ 120 VAC.
Current (isolated): 0 to 20 mA across 600 ohms maximum.
Switched Voltage (isolated): 15 VDC @ 20 mA.
DC SSR: 1.75 A @ 32 Vdc maximum.
Panel Cutout: 45 mm x 45 mm (1.775” x 1.775”).
Depth Behind Mounting Surface: 121.6 mm (4.79”) maximum.
Weight: 220 g (8 oz).
Agency Approvals: UL, C-UL E83725; CE.
Front Panel Rating: IP66, (UL Type 4X).
