Page 42
-992 RS-485 Series Communications
Port Compliance: EIA-485.
Isolation: 500 VAC.
Protocol: Lovelinks™ II.
Address Range: 001H or 3FFH.
Baud Rates: 300, 1200, 2400, 4800, 9600, 19.2k, 28.8k, 57.6k,
Mode: Half duplex.
Character: 8 bits, 1 start, 1 stop, no parity.
Number of units on line/ports
1
: 32.
Cable Lengths
1
: 6,000 ft (1,828 m).
Termination: 120 Ohms, balanced.
-993 RS-232 Series Communications
Port Compliance: RS-232C.
Isolation: 500 VAC.
Protocol: Lovelinks™ II.
Address Range: 001H or 3FFH.
Baud Rates: 300, 1200, 2400, 4800, 9600, 19.2k, 28.8k, 57.6k.
Mode: Half duplex.
Character: 8 bits, 1 start, 1 stop, no parity.
Number of units on line/ports: 1.
Cable Lengths
1
: 25 ft (7.6 m).
-995 RS-232 Series Communications
Port Compliance: RS-232C.
Isolation: 500 VAC.
Protocol: MODBUS
®
RTU.
Address Range: 001H or 0FFH.
Baud Rates: 300, 1200, 2400, 4800, 9600, 19.2k.
Mode: Half duplex.
Character: 8 bits, 1 start, 1 stop, no parity.
Number of units on line: 1.
Cable Lengths
1
: 25 ft (7.6 m).
-996 RS-485 Series Communications
Port Compliance: EIA-485.
Isolation: 500 VAC.
Protocol: MODBUS
®
RTU.
Address Range: 001H or 0FFH.
Baud Rates: 300, 1200, 2400, 4800, 9600, 19.2k.
Mode: Half duplex.
Character: 8 bits, 1 start, 1 stop, no parity.
Number of units on line/ports
1
: 32.
Cable Lengths
1
: 6,000 ft (1,828 m).
1
N
No
INPU
Type
Type
Type
Type
Type
Type
Type
Type
Type
100
100
120
1000
Curr
1
T
9
2
T
m
w
a
s
949-1265:Layout 1 1/25/11 10:23 AM Page 42
