Page 43
Termination: 120 Ohms, balanced.
1
Number can be increased through use of a repeater such as the Mother
Node™. Consult factory for details.
INPUT RANGES
INPUT TYPE RANGE °F RANGE °C
Type J or L
1
Thermocouple -100 to +1607 -73 to +871
Type K
1
Thermocouple -200 to +2500 -129 to +1371
Type T
1
Thermocouple -350 to +750 -212 to +398
Type E
1
Thermocouple -100 to +1800 -73 to +982
Type R Thermocouple 0 to 3200 -17 to +1760
Type S Thermocouple 0 to 3200 -17 to +1760
Type B Thermocouple +75 to +3308 +24 to +1820
Type C Thermocouple 0 to 4208 -17 to +2320
Type N
1
Thermocouple -100 to +2372 -73 to +1300
100 Ω Plt. 0.00385 DIN
1
RTD -328 to 1607 -200 to +875
100 Ω Plt. 0.00392 NIST
1
RTD -328 to 1607 -200 to +875
120 Ω Nickel 0.00628 US
1
RTD -112 to +608 -80 to +320
1000 Ω Plt. 0.00385 DIN
1
RTD -328 to +1607 -200 to +875
Current/Voltage/ΔVoltage
2
Scalable Units from -1999 to +9999
1
These Input Types can be set for 0.1°display. If temperature goes above
999.9°or less than -199.9°the display will return to whole degree resolution.
2
The 0 to 20 mADC, 4 to 20 mADC, 0 to 10 VDC, 2 to 10 VDC, and -10 to +10
mVDC inputs are fully scalable from a minimum of 100 counts span placed any
where within the within the range of -1999 to +9999. Decimal point position is
adjustable from the zero place (9999), tenths (999.9), hundredths (99.99), thou-
sandths (9.999), or ten thousandths (.9999).
949-1265:Layout 1 1/25/11 10:23 AM Page 43
