About the product
The Loxone Touch has five touch zones, which can be configu-
red according to your needs. The large central touch zone is
ideal for controlling lighting, whilst the corner zones are handy
for controlling music and blinds, for example.
Features
• 5 touch buttons
• Temperature & humidity sensor
• Optional click feedback
Installation
Install the mounting frame on the desired installation place.
Power up the device and pair it with your Miniserver in Loxone
Config. To finish the installation attach the Loxone Touch on
the mounting frame.
For additional information, declaration of confirmity,
visit www.loxone.com/help/touch-tree
Touch
buttons
1
2
3
4
5
Cable
This folder is a part of the product!
Connection
Wire cross-section
0.25 ... 0.8mm² / AWG23 ... 18
Stripping length
5mm / 0.2”
Temperature resistance
-40 … 105°C / -40 … 221°F
