6 -3
MT230E /
MT230HE
MT235E /
MT235HE
MT240E /
MT240HE
REAR PTO
Type Independent PTO with wet disk clutch
No. of speed 1 speed gear
PTO / Engine 540 rpm / 2509 rpm
HYDRAULIC LIFT
3 Point linkage CAT1
Draft load detection N/A
Lowering speed
control and cylinder
fixing device
Down speed control valve
Pump Gear pump type, Engine drive
Rated flow 31.2LPM (8.2GPM)
System pressure 17.0MPa (2466psi)
Lift
capacity
Lower link
end
820 kgf (1808 lbf)
24” behind
lift point
650 kgf (1433 lbf)
REMOTE
CONTROL
No. of spool Double acting , Spring return type (optional)
No. of Q/coupler N/A / 2EA / 4EA (optional)
F/Loader coupler Front outlet valve / Joystick loader valve (optional)
STEERING SYSTEM
Type Hydrostatic
Oil Transmission oil
Min. turning radius
(without brake)
LH : 3.29m (10.79 ft)
RH : 3.36m (11.02 ft)
Min. turning radius
(with brake)
LH : 2.86m (9.38 ft)
RH : 2.89m (9.48 ft)
Max. steering angle
48°
No. of steering turns 3.7 (right) / 2.9 (left) turns (lock to lock)
Rated flow
MEC: 15.6 LPM(4.1 GPM)
HST: 20.8 LPM(5.5 GPM)
System pressure 11.8MPa (1707 psi)
