LS tractor XR3037 User Manual

IMBH70. BUCKET CYLINDER
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40230928 BUCKET CYLINDER ASSEMBLY 1
2 40230929 ROD ASS'Y 1
3 40228867 CAP OUTER,∅60x∅70x37L 1
4 40228827 COVER INNER,∅60x35x55L 1
5 40228766 DUST,SDR,35x43x5/6.5 1
6 40228884 PACKING U, SKY,35x45x6 1
7 40228880 PACKING U, ISI,35x45x6 1
8 40228872 O-RING,1BG55 2
9 40228768 BUSHING DU,3520 1
10 40228876 PISTON,∅60x∅27x46L 1
11 40228870 O-RING,1BG27 2
12 40228882 PACKING U, OSI,60x50x6 2
13 40228878 RING-BACKUP,60x50x3 2
14 40228886 WEARING, WR,∅60x∅55x15L 1
15 40228864 NUT,1-14UN 1
16 40230930 TUBE ASS'Y 1
17 40231134 NIPPLE,GREASE,1/8" 2
18 40228823 SEAL KIT HEAD,NO.4~9 1
19 40228874 PISTON ASS'Y,NO.10~14 1
- 91 -

LS tractor XR3037 Specifications

General

Engine Type	Diesel
Engine Power	37 HP
Hydraulic System	Open Center
Lift Capacity	1, 808 lbs
Drive Type	4WD
Engine Cylinders	3
Transmission	Synchro Shuttle
Fuel Tank Capacity	9.5 gal
