LS RS485/Modbus-RTU - Page 14

13
Address Parameter Unit R/W Data value
26 Pulse
BIT 10
27 Sub
28 Int. 485
BIT 11
29 Option
30 Jog
BIT 12
31 PID
BIT 13 Not Used
BIT 14 Not Used
BIT 15 Set when Network malfunction occurs
0x0007 Acceleration Time
0.1 sec
R/W
0x0008 Deceleration Time
0.1 sec
R/W
0x0009 Output Current
0.1 A
R
0x000A Output Frequency
0.01 Hz
R
0x000B Output Voltage
0.1 V
R
0x000C DC Link Voltage
0.1 V
R
0x000D Output Power
0.1 kW
R
BIT 0 Stop
BIT 1 Forward Run (FX)
BIT 2 Reverse Run (RX)
BIT 3 Fault (Trip)
BIT 4 Accelerating
BIT 5 Decelerating
0x000E
Operating
Status
- R
BIT 6 Speed Arrival
BIT 7 Forward Command
BIT 8 DC Braking
BIT 9 Not Used
BIT10 Brake Open
BIT11 Forward Run Command
BIT12 Reverse Run Command
BIT13
REM. R/S (Int. 485, OPT)
BIT14 REM. Freq. (Int. 485, OPT)
0x000E
Operating
Status
- R
BIT15 Not Used
BIT 0
OCT1
BIT 1
OV
BIT 2
EXT-A
BIT 3
BX
BIT 4
LV
BIT 5
Not Used
BIT 6
GF(Ground Fault)
BIT 7 OH (Inverter overheat)
BIT 8 ETH (Motor overheat)
BIT 9 OLT (Overload trip)
BIT10
HW-Diag
BIT11
Not Used
BIT12
OCT2
BIT13
OPT (Option error)
BIT14
PO (Phase Open)
0x000F
Trip
Information
- R
BIT15
IOLTT
BIT 0
M1
0x0010 Input Terminal
Information
- R
BIT 1
M2
