Address Parameter Unit R/W Data value
BIT 2
M3
BIT 3
M4
BIT 4
M5
BIT 5
M6
BIT 6
M7
BIT 7
M8
BIT 8
P4
BIT 9
P5
BIT 10
P6
BIT11~15
Not Used
BIT 0
AUX1
BIT 1
AUX2
BIT 2
AUX3
BIT 3
AUX4
BIT 4 Q1 (OC1)
BIT 5
Q2 (OC2)
BIT 6 Q3 (OC3)
BIT 7 30AC
0x0010
Output Terminal
Information
- R
BIT 8~15 Not used
0x0012 V1 - R
0 ~FFC0
0x0013 V2 - R
0 ~FFC0
0x0014 I - R
0 ~FFC0
0x0015 RPM - R
0x001A Unit display - R
0 : Hz, 1 : Rpm
0x001B Pole number - R
0x001C Custom Version - R
※ Refer to the main manual for the communication address regarding iP5A Function
Code.
7.1.2 iP5A Communication Option Setting
< COM Group >
Address NO. Description Default Maximum Minimum
9601 COM-01
Opt B/D 0 7 0
9602 COM-02
Opt mode 0 3 0
9603 COM-03
Opt Version 0022h: Ver 2.2 - -
963C COM-60 Parity/Stop 0 3 0
* Inverter Number or communication speed is set in I/O-90, 91.
COM-01 [Opt B/D]
z Indicates the type of the option card installed.
z This value is automatically displayed when the option card is installed.
COM-02 [Opt Mode]
z Determines whether Run/Stop and Freq. command are set via communication.
Setting Display Description
0 None
None command
1 Command
Run/Stop command via communication
