15
2 Freq
Frequency command via Communication
3 Cmd + Freq
Run/Stop and Frequency command via Communication
COM-03 [Opt Version]
z Displays the version of the option card.
COM-60 [Parity/Stop]
z Sets Stop Bit or Parity Check
Setting Display Description
0 8None/1Stop Data: 8bit, Stop: 1bit, Parity: None.
1 8None/2Stop Data: 8bit, Stop: 2bit, Parity: None
2 8Even/1Stop Data: 8bit, Stop: 1bit, Parity: even
3 8 Odd/1Stop Data: 8bit, Stop: 1bit, Parity: odd
7.2. SV-iV5 Parameter Code
7.2.1 SV-iV5 Common Area
Address Parameter Unit R/W Data value
0x0000 Inverter Model - R 5: SV-iV5
SV-iV5
2:2.2 3:3.7 4:5.5 5:7.5
6:11 7:15 8:18.5 9:22
A:30 B:37 C:45 D:55
E:75 F:90 10:110 11:132
12:160 14:220
0x0001 Inverter Capacity - R
(unit : kW)
0x0002 Inverter Input Voltage - R 0: 220V class 1: 440V class
0x0003 Version - R
0100h : Ver.1.00 0110h : Ver.1.10
0x0005 Frequency Command 0.01Hz R/W 0x0502 instead of Not Used
0x0006 Run Command - R/W 0x0500 instead of Not Used
0x0007 Acceleration Time 0.1 sec R/W SV-iV5 : used in Device Net
note6)
0x0008 Deceleration Time 0.1 sec R/W SV-iV5 : used in Device Net
note6)
0x0009 Output Current 0.1 A R
0x000A Output Frequency 0.01 Hz R SV-iV5 : used in Device Net
note7)
0x000B Output Voltage 0.1 V R
0x000C DC Link Voltage 0.1 V R
0x000D Output Power 0.1 kW R
Bit00 Stop
Bit01 Forward Run (FX)
Bit02 Reverse Run (RX)
Bit03 Fault (Trip)
0x000E Operating Status - R
Bit04 Accelerating
