LS RS485/Modbus-RTU - Page 17

16
Bit05 Decelerating
Bit06 Speed Arrival
Bit07 Inverter run ready
note8)
Bit08 Stopping
Bit09 Encoder Direction Check
note9)
Bit10 Torque Limiting
Bit11 Forward Run Command
note10)
Bit12 Reverse Run Command
note10)
Bit13 Option Run/Stop Command
Bit14 Option Frequency Command
Bit15 PID Enable
note11)
Bit00
Over Current
(OCT U, V, W)
Bit01 Over Voltage(OV)
Bit02 Not Used
Bit03 BX
Bit04 Low Voltage(LV)
Bit05 Fuse Open(FO)
Bit06 Ground Fault(GF)
Bit07 Inverter Over Heat(IOH)
Bit08 E-Thermal(ETH)
Bit09 Over Load(OLT)
Bit10 HW-Diag
Bit11 External-B(EXT-B)
Bit12
Over Current2
(Arm Short U, V, W)
Bit13 Option Error
Bit14 Encoder Error
0x000F Trip Information - R
Bit15 Inverter Over Load(IOLT)
Bit00 FX
Bit01 RX
Bit02 BX
Bit03 RST
Bit04 Not Used
Bit05 Not Used
Bit06 Not Used
Bit07 Not Used
Bit08 P1
0x0010 Input Terminal
Information
- R
Bit09 P2
