21
z
FUN_01,02 determine Run/Stop command at an option by the communication.
* Run command by option uses 0x0500 of the reference data area.
* Speed command by option uses 0x0502 of the reference data area.
<I/O Group>
Address No Description Default Setting Range
725F I/O_95 Inverter Channel 1 1~250
7260 I/O_96
485 BaudRate
(Communication Speed)
3 (9600bps)
0 (1200bps) 1 (2400bps)
2 (4800bps) 3 (9600bps)
4 (19200bps) 5 (38400bps)
7261 I/O_97
Operation method when
communication command
is lost
0 (None)
0 (None continue run)
1 (FreeRun stop)
2 (Stop deceleration stop)
7262 I/O_98
Lost communication
command decision time
1.0s 1.0~30.0s
z
I/O_95,96 sets the inverter channel and the communication speed.
z
If communication command is lost when FUN_01 is 3(Option) during the time of I/O_98, the inverter
runs with the value of I/O_97.
< EXT Group >
Address No
Description Default Max Value Min Value Unit
7601 EXT_01
Opt B/D 0 7 0
7602 EXT_02
Opt Version 0022h : Ver 2.2 - -
760A EXT_10 Output Num 3 8 0
760B EXT_11 Output 1 0x0020 65535 0
760C EXT_12 Output 2 0x000E 65535 0
760D EXT_13 Output 3 0x000F 65535 0
760E EXT_14 Output 4 - 65535 0
760F EXT_15 Output 5 - 65535 0
7610 EXT_16 Output 6 - 65535 0
7611 EXT_17 Output 7 - 65535 0
7612 EXT_18 Output 8 - 65535 0
7613 EXT_19 Input Num 2 8 0
7614 EXT_20 Input 1 0x0502 65535 0
7615 EXT_21 Input 2 0x0500 65535 0
7616 EXT_22 Input 3 - 65535 0
7617 EXT_23 Input 4 - 65535 0
7618 EXT_24 Input 5 - 65535 0
7619 EXT_25 Input 6 - 65535 0
761A EXT_26 Input 7 - 65535 0
761B EXT_27 Input 8 - 65535 0
