MegaRAID SAS 9341-8i & 9341-8i
Solution Provided Low-cost, green SATA+SAS RAID solution for high-density servers and workstations with the exibility to use both SATA and
SAS hard drives and solid state drives
Physical Dimensions 9341-8i & 9341-4i: 2.6” x 6.0”
Connectors 9341-8i: Two, x4, SFF-8643 mini-SAS HD horizontal connector placement
9341-4i: One, x4, SFF-8643 mini-SAS HD horizontal connector placement
Max Number of Physical Devices Non-RAID (JBOD Mode): 64
RAID 0: 32 per volume
RAID 1: 2 per volume plus hot spare
RAID 5: 32 per volume
RAID 10: 32 per volume
RAID 50: 32 per volume
Host Bus Type 8-lane, 5 GT/s PCI Express 3.0 Compliant
Data Transfer Rates Up to 12Gb/s per port
Key RAID Data Protection Features • RAID levels 0, 1, 5, 10, 50 and JBOD mode
• Online Capacity Expansion (OCE)
• Online RAID Level Migration (RLM)
• Auto resume after loss of system power during array
rebuild or RLM
• Single controller multipathing (Load balancing)
• Drive hot plug support
• Drive roaming
• Selectable logical drive as boot drive
• Virtual Disk (VD) Consistency Check
• Fast initialization for quick array setup
• Staggered disk spin up
• Hot Spare support (up to 8)
-Global, dedicated (copy back), enclosure anity and
emergency SATA support
• Automatic rebuild support
• SafeStore Encryption Services for SED HDDs
• Shielded state drive diagnostic technology
• Patrol Read media scan and repair
• Online HDD rmware update
• Error recovery support
• SAS TCQ support
• SATA NCQ support
• Support for native 4K HDDs
• Non disk device support
• >2TB logical drive support
• Soft bad block management
• DDF-compliant Conguration on Disk
• Foreign Conguration Import
• S.M.A.R.T. support
• SES (inband) & SGPIO (sideband) management
MegaRAID Management Suite • MegaRAID Storage Manager
™
- Now with single login for domain admin
• StorCLI (command-line interface)
• CTRL-R (BIOS conguration utility)
• HII (UEFI Human Interface Infrastructure)
Environments Operating
0°C to 70°C
5 to 90% Non-condensing
Storage
-45°C to 105°C
5 to 90% Non-condensing
PCI Card Type 3.3V add-in Card
PCI Voltage +12V +/-8%
PCI Power 13.0 W (normal), 19.04 W (max)
PCI Modes Bus Master DMA
LED Indicators Internal
Activity/Fault per x4 port – Heartbeat
MTFB >2,800,000 hours
Compliances EMC: Class B-US (CFR 47, P15B); Canada (ICES-003); Japan (V-3/02.04); Europe (EN55022/EN55024); Australia/New Zealand
(AS/NZS 3548); Safety: EN60950
Regulatory Certications EN55022, EN55024, EN60950, EN 61000-3-2, EN 61000-3-3; FCC Class A, Class B; UL1950; UL; CSA C22.2; VCCI; RRL for MIC;
BSMI; C-tick
OS Support Extensive support includes Microsoft® Windows® Server 2012/Vista/2008/Server 2003/2000/XP, Linux®, Solaris™ (x86),
Netware®, FreeBSD®, VMware® and more.
Visit the LSI download center for the most complete list of supported operating systems:
http://www.lsi.com/support
Brackets Full Height and Low-Prole
Warranty 3 years, advanced replacement option
Free technical support at lsi.com/support
Ordering Information LSI SAS 9341-4i Single Pack P/N: LSI00419, LSI SAS 9341-4i Kit P/N: LSI00406
LSI SAS 9341-8i Single Pack P/N: LSI00407, LSI SAS 9341-8i Kit P/N: LSI00408
