LSIS XP Series User Manual

Chapter 1. General Introduction
1-1
Chapter 1. General Introduction
1.1 Usage of User Manual
This manual provides information of each product’s specification, usage and so on. This is necessary to use XGT Panel for medium
and large HMI system.
The user manual’s configuration is as follows.
Sequence Category Contents
Chapter 1 General Introduction It describes this manual’s configuration, product’s feature and term.
Chapter 2 System Configuration It describes feature and system configuration of each XGT Panel.
Chapter 3 Standard Specification It describes XGT Panel’s general and function specification.
Chapter 4 System Configuration It describes XGT Panel’s system configuration.
Chapter 5 Diagnostics It describes XGT Panel’s self-diagnosis.
Chapter 6
Viewing information of
PLC Connection Status
It describes the way on connection status information of PLC which is
connected with XGT Panel.
Chapter 7
Transmission of Project
from USB Storage Device
It describes the way to execute the project by using USB storage device.
Chapter 8 XGT Panel S/W Update It describes the way to update engine at XGT Panel.
Chapter 9
Backup files by using
Storage Devices
It describes the way to backup recipe, logging and etc. files by using
storage devices.
Chapter 10 Installation and Wiring It describes an installation, wiring and caution for reliability of PLC system.
Chapter 11 Maintenance
It describes inspection category and method for long normal operation of PLC
system.
Chapter 12 EMC Standard It describes system configuration for EMC standard.
Appendix 1
Troubleshooting It describes a variety of error contents and measure.
Appendix 2
Dimension It describes the dimension of XGT Panel.
Appendix 3
Warranty and
Environment Policy
-
Remark
This manual doesn’t describe connection with XP-Builder and PLC. For their own function, Please refer to the related
manuals.
