10.2 Wiring
It describes the wiring that you should know when installing the XGT Panel.
10.2.1 Power wiring
XGT Panel is divided into the DC product and the AC product.
Power Name
DC 24V
XP30-BTA(BTE)/DC
XP30-TTA(TTE)/DC
XP40-TTA(TTE)/DC
XP50-TTA(TTE)/DC
XP70-TTA/DC
XP80-TTA/DC
DC 12~24V
XP30-BTA/D1
XP50-TTA/D1
AC 100~240V
XP70-TTA/AC
XP80-TTA/AC
XP90-TTA/AC
►
If AC power is applied into the product for DC power, It may cause damage or fire.
Be careful of connection.
►
‘/DC’ is the product which use DC 24V, ‘/D1’ is the product which use DC 12~24V, and ‘/AC’ is the product
which use AC 100~240V. When using the product, Please check the label in the back of the product
.
