LUBE EGM-50TH-10S - User Manual

Questions and Answers

R
Reginald FisherAug 5, 2025
What to do if no grease is discharged from the LUBE EGM-50TH-10S Water Pump?
- M
  Mark RodriguezAug 5, 2025
  If no grease is coming out of the LUBE Water Pump, here are a few things to check: * Make sure that there is enough grease in the tank or cartridge and replenish if needed, using the same brand and grade. * Ensure you are using the correct, designated cartridge or grease. If not, replace the current grease in the pipes and valves. * Verify that the NLGI# of the grease matches the ambient temperature. * Check the wiring of the power supply and correct it if necessary. * Check the supply power voltage and correct it if it's out of specification. * Bleed any air from the pump. * If your pump has a filter, check if it's clogged and replace it if needed. * There might be problems with the pumping unit or the relief unit (such as foreign particle), so replace them.
K
kimberly63Aug 13, 2025
Why is the distributer (the valve and the grease supply pipe) of my LUBE Water Pump not discharging grease?
- M
  Madeline AndersonAug 13, 2025
  If the distributor on your LUBE Water Pump isn't dispensing grease, here are a couple of things to investigate: * Make sure the grease supply pipe is filled with grease, especially during installation. * Check the valves for clogs and replace them if necessary.
J
Jonathan MunozAug 28, 2025
What to do if the pressure in the pipe of my LUBE EGM-50TH-10S does not decrease properly?
- M
  Melissa MyersAug 28, 2025
  If the pressure in the pipe of your LUBE Water Pump isn't decreasing as it should, consider the following: * Ensure that you are using the designated cartridge or grease. If not, install the correct one and replace the grease in the pipes and valves. * Confirm that the NLGI# of the grease matches the ambient temperature. * Inspect the tubing for crashes and replace it if necessary.
C
Carlos ReyesNov 19, 2025
Why is the pressure in the main tubing of my LUBE EGM-50TH-10S Water Pump not building up?
- W
  William LiuNov 19, 2025
  If the pressure isn't building up in the main tubing of your LUBE Water Pump, it could be due to several reasons: * There might be no grease discharged from pump due to some causes. Refer to above measures. * There might be air in the tubing, so take off closure plug(s) at the end and operate pump and bleed air in tubing. * Check for grease leaks from the pump discharge port or pipe connection parts on the machine. Tighten them with the proper torque or re-pipe them. * The tubing might be damaged, so replace damaged tubing. * There might be air in the system, so refer to above measures for "Air in the pump" and "Air in the tubing". * Due to a low level of grease in the tank or the cartridge, air is introduced into the pump, so replenish with grease of the same brand and grade ...

Summary

Safety Precautions

1-1 Basic safety precautions

Emphasizes reading the manual, keeping it accessible, and using trained personnel for safety.

1-2-1 Type of labels

Illustrates various labels including Logo, Specification, Wiring, and Signal lines on the pump.

1-2-1 Caution and Refill Labels

Details caution labels for different pump types and the refill nipple label.

Specification and Outline

2-1 Specification

Provides detailed technical specifications for the pump, including voltage, current, pressure, and capacities.

2-2 Name of each component

Identifies and illustrates the main components of the EGM-50TH-10S-2C-D and -4C-D models with dimensions.

2-2 Component Identification - 7 C & 3 P Models

Identifies and illustrates components for EGM-50TH-10S-7C-D/LD/LFBD and -3P-D models.

2-2 Component Identification - 8 P Model

Identifies and illustrates components for the EGM-50TH-10S-8P-D model with dimensions.

2-3 Repair parts

Lists and illustrates repair parts such as pumping unit, relief unit, and filters for maintenance.

Installation

3-1 Environmental requirement

Specifies the required ambient temperature and humidity for operating the pump.

3-2 Mounting unit

Details how to securely mount the pump, including required bolts and optional anti-vibration rubber.

3-3 Wiring

Provides instructions and diagrams for correctly connecting the pump's power and signal wiring.

3-3-1 DIN connector wiring diagram

Shows wiring diagrams for DIN connectors for various pump models and signal types.

3-3-2 DIN connector connection procedure

Details the step-by-step procedure for connecting wires to the DIN connector on the pump.

3-4 Tubing connection

Explains how to connect the discharge tubing, including pressure requirements and proper fastening.

Setting of Timer on Machine

4. Setting of Timer on Machine

Instructs on how to install and set timers for discharge and interval cycles for pump operation.

Refilling Grease

5-1 Grease refilling method

Lists the appropriate grease refilling methods and compatible grease types for different pump models.

5-2 Replacement of grease cartridge

Details the procedure for replacing the grease cartridge, emphasizing correct usage and warnings.

5-3 Grease replenishment method (for tank type only)

Explains how to replenish grease in tank-type pumps using a grease gun and designated grease.

Maintenance

6-1 Bleeding air

Provides step-by-step instructions for bleeding air from the pump, including safety precautions.

6-2 Replacement of pumping unit

Details the procedure for replacing the pumping unit using special tools and applying grease.

6-2 Replacement of relief unit

Explains the process of replacing the relief unit, including tool usage and applying grease.

6-2 Replacement of filter

Describes how to replace the filter for 7C-D models, including removal and installation steps.

6-2 Filter Replacement - 7 C-LD;LFBD Models

Details filter replacement for 7C-LD and 7C-LFBD models, including installation checks.

6-3 Troubleshooting

Provides a table listing common troubles, their causes, and recommended measures for resolution.

Appendix. Grease contamination: Causes and measures

Causes

Categorizes causes of grease contamination into pre-installation and during operation stages.

Measures

Outlines steps to prevent grease contamination, focusing on proper handling during cartridge exchange and storage.

LUBE EGM-50TH-10S Specifications

General

Brand	LUBE
Model	EGM-50TH-10S
Category	Water Pump
Language	English
