363-205-401 Power Up:
Issue 7, March 1997 Page 1 of 6
DLP-506
Install 336A Rectifiers in J1C182BA Power Shelf
SUMMARY:
Insert
336A RECTIFIER
into power shelf. Measure −42 to −56 V DC at
LDU
(−
48B
/
GND
). Unseat
336A RECTIFIER
and repeat for additional
336A
RECTIFIER
s. Reseat all
336A RECTIFIER
s.
1.
NOTE:
Two
336A RECTIFIER
s are required for one dual bank assembly and an
additional two
336A RECTIFIER
s (total of four) are required for a second
dual bank assembly.
Get required number of
336A RECTIFIER
s and inspect for possible physical
damage.
2.
NOTE:
All
BATTERY CHARGER
s must be unseated throughout this procedure.
Verify that fuse on
336A RECTIFIER
s (Figure 1) is not blown.
