363-205-401 RT Turn Up: DLP-505
Issue 7, March 1997 Page 3 of 6
5.
!
CAUTION:
Incorrectly set ADU option switches may result in immediate or future
loss of service or may introduce errors into the digital bitstream.
Insert
ADU
into lower
ADU
slot if equipping blue bank or upper
ADU
slot if
equipping white bank.
Response: Disregard all indicators that may be lighted.
6.
NOTE:
When the BCU is first installed, the ADU should be set for preservice and
unequipped digroups (AB and CD) to verify these units (ADU and BCU)
are functioning properly (all alarms clear).
Install BCU.
Reference: DLP-508
Response: After approximately 1 minute, all indicators will go off. MISC( )
may be lighted. Clear power shelf trouble is you have a
MJ/MN NE alarm using 363-205-500 Maintenance TOP.
7.
!
CAUTION:
Incorrect ADU option switch settings can cause service interruptions. Do
not change any option switches except the ones listed for equipping
digroups. For FPB Mode 1 systems, removing the ADU will interrupt
service on digroup A. Therefore, this procedure requires that a Mode 1
system has all digroups equipped.
NOTE:
If the ADU you are installing is a replacement, the system configuration
(positions 1,2,7, and 8) options must be set as directed in the previous
Steps.
Remove
ADU
(Figure 1) from bank being equipped.
8. Set switch
S2
positions
5
and
6
as follows:
•
5
- Toward the number (closed) to option digroup AB equipped.
•
6
- Toward the number (closed) to option digroup CD equipped (if
required).
