363-205-401 RT Turn Up: DLP-512
Issue 7, March 1997 Page 9 of 12
13. Did
FAIL
indicator on
LIU
light momentarily?
If
YES,
then proceed to Step
26.
If
NO,
then continue with Step
14.
14. Replace
LIU
with correctly optioned
LIU
while observing
FAIL
indicator on
LIU
faceplate.
15. Did
FAIL
indicator on
LIU
light momentarily?
If
YES,
then proceed to Step
26.
If
NO,
then continue with Step
16.
16. Replace
TRU
associated with LIU. (TRU in AB shelf for LIUs A, B, or P. TRU in
CD shelf for LIU C or D.)
17. Replace
LIU
with
LIU
removed previously while observing
FAIL
indicator on
LIU
faceplate.
Table E
LED Indicators for Digroups CD
System Configuration
LIU
(Note)
ADU BCU
Digroups CD (and P)
to be Equipped
Protection Feature Package ( ) MJ MN NE C D
When Adding
Protection
A, B Mode 1, or C
C on on off on
D off on on off
P off off
B Mode 2 or D
C off on on off off
P off off
When Not Adding
Protection
A, B Mode 1, or C
C on on off on
D off off off
B Mode 2 or D C off off off off
Note: LIU to be installed
To Next Page
