Operating Manual V25/09.2019 Ventus / Ventus-X / V200A
Chapter 20 Appendix 60
Device configured for measurement values in US units:
Measurement Value
UMB
Channel
Min
Max
Unit
Buffer ‘0’
Air Temperature (act)
105
-58.0
158.0
°F
Wind Speed(act)
410
0.0
201.3
Mph
Wind Speed (max)
450
0.0
201.3
mph
Wind Speed (avg)
470
0.0
201.3
mph
Buffer ‘1’
Wind Direction (act)
500
0.0
359.9
°
Wind Direction (vct)
580
0.0
359.9
°
Wind Quality
805
0.0
100.0
%
Rel. Air Pressure (act)
305
300.0
1200.0
hPa
Air Density (act)
310
0.000
3.000
kg/m³
Buffer ‘2’
Wind Speed(min)
430
0.0
201.3
mph
Wind Speed(vct)
490
0.0
201.3
mph
Wind Direction (min)
520
0.0
359.9
°
Wind Direction (max)
540
0.0
359.9
°
Buffer ‘3’
Air temperature (min)
125
-58.0
158.0
°F
Air temperature (max)
145
-58.0
158.0
°F
Air temperature (avg)
165
-58.0
158.0
°F
Buffer ‘4’
Rel. Air Pressure (min)
325
300.0
1200.0
hPa
Rel. Air Pressure (max)
345
300.0
1200.0
hPa
Rel. Air Pressure (avg)
365
300.0
1200.0
hPa
20.6.5 Additional Measurement Commands
With the additional measurement commands
aM1! … aM3!
aMC1! … aMC3! (M command, data transmission with CRC)
aC1! … aC3!
aCC1! … aCC3! (C command, data transmission with CRC)
the complete range of measurement data of the Ventus , as defined for the UMB protocol, is also
available in a SDI-12 environment.
The measurement values are grouped according to sensor types.
As for the base data, an M command only permits to request up to 9 measurement values. With
C commands, up to 20 values are available.
The buffer assignment defined below is thus structured in a way, that the resp. M command
uses the D0 and D1 buffers. If more values are available for the sensor type, the C command
will also fill the buffers D2 to D4 (if required)
M1 / C1 Temperature M: 4 Values C: 4 Values
M2 / C2 Wind M: 9 Values C: 10 Values
M3 / C3 Air Pressure M: 8 Values C: 8 Values
