1. When setting controller for LED drivers/fixtures;
Using a pointed tool (ball point pen) press [SET] button to select 0-10V analogue
signal protocol (0-10V LED indictor light on only). This will make both zones com-
patible for LED drivers.’
2. When setting controller for HID ballast/fixtures;
Press [SET] button to select RS485 digital signal protocol (LED indicator light on).
This will make both Zones compatible for HID electronic ballasts.
3. When setting controller for LED drivers/fixtures and HID ballast/fixtures;
Press [SET] button to select both 0-10V & RS485 signal protocols ( both LED indica-
tor lights on). This will make Zone A compatible for LED drivers and Zone B com-
patible for HID electronic ballasts.
‘To set temperature scale and power output unit of measurement:
Press [OK] and then [>] to ‘System Settings’ and [OK] to enter
Press [<]or[>] to ‘Temp’ and [^]or[v] to toggle between ‘C’ (Celsius) or ‘F’ (Faren-
heit). Press [OK] to save.
Press [<]or[>] to ‘Power’; the display will show either % (percent) when LED is select-
ed in ‘Type’ in Zone A/B page and W (Watts) when HID is selected.
Note! LED driver power output is shown as a percentage of the driver ‘s nominal
power output eg. 50% of a 1000W LED driver is 500W.
To set Time and Date to your local time;
Press [OK] and then [>] to System Settings and [OK] to enter
In System Settings press [<]or[>] to Hour and [^]or[v] to toggle between 24hour and
am/pm clock. Press [OK] to save.
Press [<]or[>] to Time and [^]or[v] to set time in hours and minutes and [OK] to save.
Press [<]or[>] to Date and [^]or[v] to set date in Day [D], Month [M] and Year [Y]
and [OK] to save.’
Press [OK] to enter Home screen
Press [<]or[>] to ZONE A and [OK] to enter
Setting ballast/driver/fixture type:
Press [<]or[>] to Type and [^]or[v] to select ballast/driver type and Press [OK] to save.
Setting light intensity by selecting power output level:
Warning! New HID lamps need to run at nominal power for at least 100 hours to ensure they
don’t fail prematurely. If using new lamp; set Power to 100%. After 100 hours nominal power
use, new HPS lamps may be dimmed and boosted and MH/CMH lamps may be dimmed.
Warning! Do not boost MH/CMH lamps which must not exceed their nominal power.
2. System Settings
3. Setting Signal Protocol
4. Setting Zone Parameters
