Lumberjack Log Lock - Page 4

Assembly Parts Included:
4
● 1/2” Handle
● 1/4” x 3-3/4” Bolt
● 1/4” Nut
● 1/4” Washer
(QTY:2)
● 3/8” x 1” Bolt
(QTY:2)
● 3/8” Washer
(QTY:2)
● 3/8” Nut
(QTY:2)
Note: Images not to scale
Assembly Parts Not Included:
● Wood screws QTY:4 (#8 or larger)
- Used for mounting fixture to table/workbench
● 1/2” x 6” Carriage Bolt
● 1/2” Jam Nut
● 1/2” Washer
(QTY:2)
● 1/2” Spring
2A
2B
2C
2D
● Fixture Top
1A
● Fixture Bottom
1B
● Fixture Ladder
1C
4A
4C
4B
3A
3B
3A
5A
