Lumens VS-K20 User Manual

English - 10
Chapter 3 Setting Menu
<Remark> Press [SETUP] on the remote control to enter the setting menu; the
bold underlined values in the following table are defaults.
1
st
Level
Major Items
2
nd
Level
Minor Items
3
rd
Level
Adjustment
Values
Function
Descriptions
CAMERA
SETTING
CAMERA ID
1~ C ~255
Set camera ID
VISCA only works with
ID 1~7
PROTOCOL
V
V：VISCA，ID 1~7
PD
PD ： PELCO D ， ID
8~255
BAUD RATE
1. 9600
2. 38400
Set baud rate. This
baud rate must be the
same as the camera’s
baud rate.
ADDRESS
1~ C ~255
Camera’s address,
this address must be
the same as the
camera’s ID.
TIME
SETTING
SET TIME
xx:xx:xx
Set time in 24 hour
format
TIME
DISPLAY
-
1. ON
2. OFF
Set the time display
VOLUME
SETTING
-
1. OFF
2. 1~6
Adjust the volume of
the controller
KEYBOARD
LIGHT
-
1. AUTO
2. ON
3. OFF
Set the backlight of
the controller on or off
SLEEP
SETTING
-
1. OFF
2. 60M
3. 30M
4. 10M
5. 5M
6. 1M
7. 30S
Set sleep time of the
controller.
PIN
SETTING
-
1. USER
2. ADMIN
Set user and admin
pins of the controller
