68
you do not travel with a flush-water tank
that is too full. Do not travel with water in
the toilet bowl. Failure to adhere to this
notice may result in water damage to your
caravan or motor home.
Using the toilet with Optional Features
13. Electric Blade: Push the electric blade
button on the control display to
electrically open or close the blade. In the
case of failure, you can manually open or
close the blade by sliding the small
handle under the toilet bowl sideways.
14.
Automatic Ventilator: The ventilator
automatically starts when the control
panel is activated (by pressing the flush
button) and will automatically shut off
after approximately 5 minutes. The
Automatic Ventilator Indicator will flash
until automatic shut-off occurs. If you
want to stop the ventilator, press the
Automatic Ventilator button. If you want
to re-start the ventilator, press the button
again (the LED will start flashing again).
15.
Flush Water Tank Level Indicator (only for
toilets with own flush-water tank): When
the Flush Water Tank Level Indicator
lights up, refill the flush-water tank, as
only about 1.5 litres of water is left in the
tank, which is sufficient for approximately
2 flushes.
Emptying
The Waste Holding Tank has a capacity of 18
litres and requires emptying when the red
light (LED) on the toilet control display lights
up, when the Waste Holding Tank only has
capacity for approximately 2 more litres,
which is no more than two to three further
uses.
Make sure that the blade is closed. Open the
access door located outside the vehicle, pull
the safety catch upwards and remove the
Waste Holding Tank.
16. Place the Waste Holding Tank in an
upright position (Pull-Out Handle at the
top, Wheels at the bottom). Slide the
handle sideways - to the front of the tank
- until it snaps out of its locked position.
17. Pull the handle up and wheel the Waste
Holding Tank to an authorized waste
disposal point.
18. Push the handle back into its locked
position. Turn the emptying spout
upwards and remove the cap from the
spout. Hold the Waste Holding Tank in
such a way that during emptying you can
operate the vent plunger with your
thumb. To empty the tank without
splashing, depress the vent plunger while
emptying the tank. After emptying, rinse
the tank and blade thoroughly with water.
WARNING: Do not seriously shake the
tank or use high pressure water cleaners.
This may cause damage to the tank’s
interior.
Note: The vent plunger should only be
depressed once the emptying spout is
pointing downwards. Prepare the toilet for
re-use if required. Slide the Waste Holding
Tank into the toilet and close the access
door.
Emptying with Optional Features
19. Waste Holding Tank Multi-Level Indicator:
The lower lamp indicates that the Waste
Holding Tank is almost empty; the middle
lamp indicates that it is more than half
full; when the upper lamp lights up, the
tank needs emptying as it can only take 2
- 3 further uses.
Note: The Waste Holding Tank Level
Indicator will flash when the holding tank is
not present. In this case the toilet will not
flush.
20. Waste Pump-Out System: When
activating the control panel this feature
automatically lights up. When the Waste
Holding Tank Level Indicator illuminates,
press the Waste Pump-Out button to
pump out the waste from the holding tank
into the vehicle’s waste tank. The button
will flash while the waste is being
THETFORD TOILETS
