LUTEC 7297801012 - Page 5

Remove the preassembled nuts and washers from the
expansion bolts (AA). Then put the expansion bolts (AA) into
the drill holes.
Hardware Used
Expansion Bolt x 3
AA
C
7. Use the positioning paper (CC) to drill three holes on the
ground.
Hardware Used
Positioning Paper x 1
CC
Wrench x 1
Hardware Used
Hexagon Screw x 3
BB
DD
Rotate the top pole (C) clockwise onto the middle pole (D).
6.
8.
7
8
6
5. Secure the middle pole (D) to the base (E) with the hexagon
screws (BB) by using the wrench (DD).
5
E
D
5
BB
D
C
CC
AA
