Lutron Athena System User Guide
Lutron App
The Lutron app is available on the Apple App Store. The app can be used to connect with an Athena system
via the cloud or local network, control and monitor lighting, as well as make changes to system / scene
programming.
App Features
• Connect to system securely via cloud or local network
• View current levels of system lighting
• Navigate area hierarchy to view lighting zones
– Easily toggle all lights on / off in an area
• Activate scenes within areas
• Control lights
– Adjust all lights in area together with master control
– Control individual lighting zones (app controls for zone types described below)
Load Type Intensity Control CCT Control Color Palette
Ketra
X X X
0-10 V (static white)
X
0-10 V (tunable white CCT / INT)
X
T-Series
X
DMX*
X
DALI
X
Contact Closures
X
* Loads configured as DMX 1-channel in Lutron Designer will be shown with a 0-100% slider in the app. Multi-channel DMX fixtures may be configured
as multiple 1-channel loads.
• Scene editing
– Modify the light levels for area scenes
– User experience tailored for Lighting Designer scene tuning
– Fine-tuning mode
– Use phone's camera to select a color
– Set the Fade properties for the scene (for all dimming loads)
– Set the Delay properties for the scene (for non-Ketra loads)
– Specify zones as affected / unaffected for the scene
– For tunable white lighting (0-10 V, T-Series, DMX, DALI) only intensity can be edited
