Signal The signal adjusting circuit is used the
Stability digital synthesis circuit, the output
signal will existing high stability and
not change.
Power Less than 30 Watt.
Consumption
Operating Temp. 0 to 50 (32 to 122 ).℃℉
Operating Less than 80% R.H.
Humidity
Dimension 21 x 12 x 12 cm (8.3 x 4.8 x 4.8 inch).
Weight 1Kg/2.2 LB.
Housing Compact and impact plastic injection
case with plastic mirror type reflector.
Calibration Crystal time base and microprocessor
circuit, don't necessary take any
external calibration process.
Accessories Operation manual............
1 PC.
Included Power cable.....................1 PC.
2-2 Flash Tube Specification
Flash tube Xenon lamp.
Flash Duration Approximately 60 to 1,000
microseconds.
Flash color Temp. Xenon white 6,500 K degree.
Flash energy 4 Watts-seconds (joules).
Beam Angle 80 degrees.
Flash tube It is required to change the flash tube
replacement when the instrument start to flash
irregularly at speeds > 3600 RPM/FPM.
Operating duty For prolong life and safety, please
Cycle adhere to the following operation duty
cycle: < 2000 RPM - 2 hours
2001 to 3600 RPM - one hour
3601 to 8000 RPM - 30 minutes
> 8000 RPM - 10 minutes.
* 10 min. cooling off period between cycles.
3
