Processor
Connect Ethernet wiring to each processor
Every HomeWorks QS processor must be wired to the same local area network. Ethernet is required
for inter-processor communication and for 3
rd
party integration.
Legacy Devices
Terminal 2 is unused for Q96 Interfaces
Do not connect terminal 2 between Q96 Interfaces and the Processor. All Q96s get powered from
the QED shade power supply and do not need to be powered from the Processor.
Terminal 2 is unused for HWI Keypads
HWI Wired keypads require 15V DC power (do not use 24V DC from link)
