Maestro Sensor
369666f 18 09.05.19
®
SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
Switch with Occupancy / Vacancy Sensor
OR
Black
Blue
Ground
Occupancy
sensor switch
Green
Ground
120 V~
50 / 60 Hz
Hot / Live
Neutral
Load
Standard
mechanical switch
Black
Jumper wire
Bare
Different color screw
(Common)
Green
screw
Black
Blue
Green
Ground
Occupancy
sensor switch
Ground
120 V~
50 / 60 Hz
Hot / Live
Neutral
Load
Standard
mechanical switch
Black
Jumper wire
Bare
Different color screw
(Common)
Green
screw
3-way Installation with Standard Mechanical Switch (120 V~)
3, 4
-OPS6M2U-DV, -VPS6M2U-DV
Wiring Diagram 8 - without Neutral
Wiring Diagrams (continued)
1
When using controls in single location installations, tighten the blue terminal or cap blue wire. Do NOT connect the blue terminal / wire to any other
wire or to ground.
2
Fan load applies to 120 V~ only (not for 277 V~).
3
Only one occupancy sensor switch can be used per multi-location circuit.
4
A single standard mechanical 3-way switch or up to 9 companion switches may be connected to most occupancy sensor switches.
Standard mechanical 3-way switch cannot be combined with companion switch. Total blue terminal wire length may be up to 150ft (46m).
Continued on next page...
Note: Remove white sleeve and connect green wire to ground only in retrofit and replacement applications.
