D9 Decimal Point(DP), position from right to the
left
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D10 Polarity
0 = Positive 1 = Negative
D11 & D12 Annunciator for Display
= 01 ℃ = 02℉
D13 When send the up display data = 1
When send the middle display data = 2
When send the low display data = 3
D14 4
D15 Start Word
RS232 FORMAT : 9600, N, 8, 1
Baud rate 9600
Parity No parity
Data bit no. 8 Data bits
Stop bit 1 Stop bit
12. Optional Type K Temp. probe
(Type K) TP-01
* Max. short-tern operating
Temperature: 300 (572 ).℃ ℉
* It is an ultra fast response
naked-bead thermocouple
suitable for many general purpose
application.
Thermocouple
* Measure Range: -50 to 900 ,℃ ℃
Probe
-50 to 1650 .℉ ℉
(Type K), TP-02A
* Dimension:10cm tube, 3.2mm Dia.
Thermocouple
* Measure Range: -50 to 1200 ,℃ ℃
Probe
-50 to 2200 .℉ ℉
(Type K), TP-03
* Dimension: 10cm tube, 8mm Dia.
Surface Probe
* Measure Range: -50 to 400 ,℃ ℃
(Type K), TP-04
-50 to 752 .℉ ℉
* Size :
Temp. sensing head - 15 mm Dia.
Probe length - 120 mm.
