GB
31
If you can’t fix the fault yourself, contact your nearest
vendor. Please be aware that any improper repairs
will also invalidate the warranty and additional costs
may be incurred.
Disposal
Disposal of the appliance
This appliance must not be disposed of with regular
household waste! Dispose of the appliance in the
appropriate manner. For more information, consult
your community waste disposal service.
A crossed-out wheelie bin icon means: Bat-
teries and rechargeable batteries, electrical
or electronic devices must not be disposed of
with household waste. They may contain
substances that are harmful to the environ-
ment and human health.
Consumers must dispose of waste electrical devices,
spent portable batteries and rechargeable batteries
separately from household waste at an official collec-
tion point to ensure that these items are processed
correctly. Information on returning these items is
available from the seller. Sellers are required to
accept these items free of charge.
Batteries and rechargeable batteries, which
are not permanently installed in waste elec-
trical devices, must be removed prior to dis-
posal and must be disposed of separately.
Lithium batteries and battery packs in all systems
must only be retuned to a collection point when dis-
charged. Batteries must always be protected against
short circuits by covering the poles with adhesive
tape.
All end users are responsible for deleting any per-
sonal data stored on waste devices prior to their dis-
posal.
Disposal of the packaging
The packaging consists of cardboard and
correspondingly marked plastics that can
be recycled.
– Make these materials available for
recycling.
Technical data
*) The specified values are emission values and do not necessarily
represent safe workplace values. Although there is a correlation
between emission and immission levels, this cannot be used to
infer whether additional safety measures are necessary or not.
Factors which affect the current immission levels at the work-
place, include the type of room, other sources of noise, e. g. the
number of machines operating and other processes taking
place in the vicinity. Permitted workplace values can differ from
country to country. This information is designed to help the user
to better assess the dangers and risks. Determination of noise
emission values in accordance with EN 62841-1.
**) The specified vibration emission value was measured in accord-
ance with a normed test procedure and can be used in order to
compare one tool with another. The specified vibration emission
value can also be used for an introductory evaluation of the
exposure. The vibration emission value may fluctuate from the
specified value during actual use of the power tool. These fluc-
tuations will depend on the way in which the power tool is used.
Try to keep vibrations to a minimum. One method of reducing
the vibration load is, for example, limiting the length of time you
work with the tool. All parts of the operating cycle must be taken
into account for this purpose (for example, also including times
in which the power tool is switched off and times in which it is
switched on, but is running without load). Determination of vibra-
tion emission values in accordance with EN 62841-1 &
EN 62841-2-1.
Accessories
Accessories are available from your local vendor.
Battery pack defective? Contact your local vendor.
Tool holder does not turn. Is the rotation direction switch set
to the centre setting?
Changing the rotation direction –
p. 30.
Error/Fault Cause Remedy
Part number 101787
Cordless drill set
Rated voltage 20 V
Idle revolutions 0–400 /
0–1400 min
-1
Max. torque 35 Nm
Max. drill chuck diameter 13 mm
Sound power level (L
WA
)* 77 dB(A)
(K = 5 dB(A))
Sound pressure level (L
PA
)* 66 dB(A)
(K = 5 dB(A))
Vibrations** < 3,2 m/s²
(K = 1,5 m/s²)
Weight 1,8 kg
Battery charger
Rated voltage 230 V~, 50 Hz
Rated output 70 W
Charge voltage 20,9 V
Charge current 2400 mA
Protection class II
Battery pack
Battery pack type Li-Ion
Rated voltage 20 V
Capacity 2 Ah
Charging time 60 min
Item num-
ber
Accessory
196051 Battery pack 2 Ah
196052 Battery pack 4 Ah
196054 Battery charger
196055 Battery charger
196053 Battery set with charger
Part number 101787
