Faults and remedial measures
When something isn’t working…
Malfunctions are often caused by minor
faults. You can easily remedy most of these
yourself. Please consult the following table
before contacting the vendor. You will save
yourself a lot of trouble and possibly money
too.
If you can’t fix the fault yourself, contact your
nearest vendor. Please be aware that any
improper repairs will also invalidate the war-
ranty and additional costs may be incurred.
Disposal
Disposal of the appliance
Appliances which are labelled with
the adjacent symbol must not be dis-
posed of in household waste. You
must dispose of such old electrical
and electronic equipment separately.
– Please check with your local authority
about the possibilities for correct dis-
posal.
Through separate disposal you send old
equipment for recycling or for other forms of
re-use. You will thus help to avoid in
somecases that damaging material gets into
the environment.
Disposal of the packaging
The packaging consists of card-
board and correspondingly marked
plastics that can be recycled.
– Make these materials available
for recycling.
Technical data
*) The specified values are emission values and do not necessar-
ily represent safe workplace values. Although there is a corre-
lation between emission and immission levels, this cannot be
used to infer whether additional safety measures are necessary
or not. Factors which affect the current immission levels at the
workplace, include the type of room, other sources of noise,
e.g. the number of machines operating and other processes
taking place in the vicinity. Permitted workplace values can dif-
fer from country to country. This information is designed to help
the user to better assess the dangers and risks.
**) The specified vibration emission value was measured in
accordance with a normed test procedure and can be used in
order to compare one tool with another. The specified vibration
emission value can also be used for an introductory evaluation
of the exposure. The vibration emission value may fluctuate
from the specified value during actual use of the power tool.
These fluctuations will depend on the way in which the power
tool is used. Try to keep vibrations to a minimum. One method
of reducing the vibration load is, for example, limiting the length
of time you work with the tool. All parts of the operating cycle
must be taken into account for this purpose (for example, also
including times in which the power tool is switched off and
times in which it is switched on, but is running without load).
Appropriate chain oil
DANGER! Risk of injury! Improp-
erly performed repairs can lead to the
device not functioning safely. This
endangers yourself and your envi-
ronment.
Fault/malfunction Cause Remedial measure
Motor not running. No mains voltage? Check cable, plug, socket and
fuse.
Cable faulty? Have replaced by an electri-
cian.
Item number 468 283
Nominal voltage 230V~/50Hz
Nominal output 710W
Protection class II
Cutting speed 13m/s
Idling speed 8500min
-1
Cutting length 180mm
Oil tank capacity 150ml
Noise pressure level
(L
PA
)*
83dB(A)
Sound power level (L
WA
)* 103dB(A)
Vibration <3.64m/s²
(K= 1.5m/s²)
Weight 4.5kg
Dimensions 2300 × 135 ×
60mm
Overall length 2290–2890 mm
Saw chain Oregon
90JG033X
Chain division 9,525 mm (3/8")
Saw rail Oregon 080NATA
A041, 200 mm
(8")
NOTICE! Risk of damage to the
device! Under no circumstances
should you use old oil to grease the
saw chain! This can cause damage to
the oil pump, saw rail and chain!
Item number 468 283
