Luxaire TC7B3021S - Page 33

5186767-LTG-B-0816
Johnson Controls Unitary Products 33
TC7B4221S TMLV120C20MP11 21.0 CF/CM/CU48D 1225 41.5 28.2 16.50 13.75
TC7B4221S TMLV120C20MP11 21.0 CF/CM/CU60C 1225 42.0 28.8 16.50 13.75
TC7B4221S TMLV120C20MP11 21.0 CF/CM/CU60D 1225 42.0 28.8 16.50 13.75
TC7B4221S TMLV120C20MP11 21.0 CF/CM64D 1200 41.5 27.8 16.50 13.75
TC7B4221S TMLX080B12MP11 17.5 CF42B 1175 40.0 26.8 15.75 13.00
TC7B4221S TMLX080C16MP11 21.0 CF/CM/CU42C 1200 40.5 26.8 16.25 13.25
TC7B4221S TMLX080C16MP11 21.0 CF/CM/CU42D 1200 41.0 27.6 16.25 13.50
TC7B4221S TMLX080C16MP11 21.0 CF/CM/CU48C 1200 41.0 27.4 16.50 13.50
TC7B4221S TMLX080C16MP11 21.0 CF/CM/CU48D 1200 41.0 27.4 16.50 13.50
TC7B4221S TMLX080C16MP11 21.0 CF/CM/CU60C 1200 41.5 27.8 16.50 13.75
TC7B4221S TMLX080C16MP11 21.0 CF/CM/CU60D 1225 42.0 28.8 17.00 14.00
TC7B4221S TMLX080C16MP11 21.0 CF/CM64D 1200 42.0 28.0 17.00 13.75
TC7B4221S TMLX100C16MP11 21.0 CF/CM/CU42C 1200 40.5 26.8 16.25 13.25
TC7B4221S TMLX100C16MP11 21.0 CF/CM/CU42D 1200 41.0 27.6 16.25 13.50
TC7B4221S TMLX100C16MP11 21.0 CF/CM/CU48C 1200 41.0 27.4 16.50 13.50
TC7B4221S TMLX100C16MP11 21.0 CF/CM/CU48D 1200 41.0 27.4 16.50 13.50
TC7B4221S TMLX100C16MP11 21.0 CF/CM/CU60C 1200 41.5 27.8 16.50 13.75
TC7B4221S TMLX100C16MP11 21.0 CF/CM/CU60D 1225 42.0 28.8 17.00 14.00
TC7B4221S TMLX100C16MP11 21.0 CF/CM64D 1200 42.0 28.0 17.00 13.75
TC7B4221S TMLX100C20MP11 21.0 CF/CM/CU42C 1275 41.0 28.4 16.50 13.50
TC7B4221S TMLX100C20MP11 21.0 CF/CM/CU42D 1275 41.0 28.4 16.50 13.50
TC7B4221S TMLX100C20MP11 21.0 CF/CM/CU48C 1275 42.0 29.0 17.00 14.00
TC7B4221S TMLX100C20MP11 21.0 CF/CM/CU48D 1300 42.0 28.6 17.00 14.00
TC7B4221S TMLX100C20MP11 21.0 CF/CM/CU60C 1275 42.0 29.4 17.00 14.00
TC7B4221S TMLX100C20MP11 21.0 CF/CM/CU60D 1275 42.0 29.4 17.00 14.00
TC7B4221S TMLX100C20MP11 21.0 CF/CM64D 1275 42.0 29.0 17.00 14.25
TC7B4221S TMLX120C20MP11 21.0 CF/CM/CU42C 1275 41.0 28.4 16.50 13.50
TC7B4221S TMLX120C20MP11 21.0 CF/CM/CU42D 1275 41.0 28.4 16.50 13.50
TC7B4221S TMLX120C20MP11 21.0 CF/CM/CU48C 1275 42.0 29.0 17.00 14.00
TC7B4221S TMLX120C20MP11 21.0 CF/CM/CU48D 1300 42.0 28.6 17.00 14.00
TC7B4221S TMLX120C20MP11 21.0 CF/CM/CU60C 1275 42.0 29.4 17.00 14.00
TC7B4221S TMLX120C20MP11 21.0 CF/CM/CU60D 1275 42.0 29.4 17.00 14.00
TC7B4221S TMLX120C20MP11 21.0 CF/CM64D 1275 42.0 29.0 17.00 14.25
TC7B4221S TP9C060B12MP12 17.5 CF42B 1275 40.5 28.0 15.25 12.50
TC7B4221S TP9C080B12MP12 17.5 CF42B 1275 40.5 28.0 15.25 12.50
TC7B4221S TP9C080C16MP12 21.0 CF/CM/CU42C 1275 41.0 28.2 16.20 13.25
TC7B4221S TP9C080C16MP12 21.0 CF/CM/CU48C 1275 42.0 28.8 16.50 13.50
TC7B4221S TP9C080C16MP12 21.0 CF/CM/CU48D 1175 41.5 27.8 17.00 13.75
TC7B4221S TP9C080C16MP12 21.0 CF/CM/CU60C 1200 41.5 27.8 16.50 13.75
TC7B4221S TP9C080C16MP12 21.0 CF/CM/CU60D 1425 42.0 30.4 16.50 13.50
TC7B4221S TP9C080C16MP12 21.0 CF/CM64D 1300 42.0 29.4 16.50 13.75
TC7B4221S TP9C100C16MP12 21.0 CF/CM/CU42C 1275 41.0 28.2 16.20 13.25
TC7B4221S TP9C100C16MP12 21.0 CF/CM/CU48C 1275 42.0 28.8 16.50 13.50
TC7B4221S TP9C100C16MP12 21.0 CF/CM/CU48D 1175 41.5 27.8 17.00 13.75
TC7B4221S TP9C100C16MP12 21.0 CF/CM/CU60C 1200 41.5 27.8 16.50 13.75
TC7B4221S TP9C100C16MP12 21.0 CF/CM/CU60D 1425 42.0 30.4 16.50 13.50
TC7B4221S TP9C100C16MP12 21.0 CF/CM64D 1300 42.0 29.4 16.50 13.75
TC7B4221S TP9C100C20MP12 21.0 CF/CM/CU42C 1275 41.0 28.2 16.00 13.00
TC7B4221S TP9C100C20MP12 21.0 CF/CM/CU48C 1275 42.0 28.8 16.50 13.50
TC7B4221S TP9C100C20MP12 21.0 CF/CM/CU48D 1275 42.0 28.4 16.50 13.75
TC7B4221S TP9C100C20MP12 21.0 CF/CM/CU60C 1275 42.0 29.2 16.50 13.50
TC7B4221S TP9C100C20MP12 21.0 CF/CM/CU60D 1250 42.0 29.0 16.50 13.75
TC7B4221S TP9C100C20MP12 21.0 CF/CM64D 1225 42.0 28.6 17.00 14.00
Continued on next page.
COOLING CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
