Luxaire TC7B3021S - COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)

5186767-LTG-B-0816
Johnson Controls Unitary Products 9
— = Not applicable.
MP Modular Air Handlers use Coil Only Ratings.
TC7B6021S AVC60CX21 21.0 – 1750 56.5 40.0 14.75 12.25
TC7B6021S AVC60DX21 24.5 – 1650 58.0 40.5 15.50 13.00
TC7B6021S ME16CN21 21.0 CF/CM60C 1725 57.0 41.0 15.25 12.75
TC7B6021S ME20DN21 24.5 CF/CM60D 1650 56.5 39.0 15.25 12.75
TC7B6021S ME20DN21 24.5 CF/CM64D 1625 58.0 40.0 15.75 13.00
TC7B6021S MVC16CN21 21.0 CF/CM60C 1625 56.0 39.0 15.00 12.50
TC7B6021S MVC20DN21 24.5 CF/CM60D 1650 56.5 39.5 15.50 12.75
TC7B6021S MVC20DN21 24.5 CF/CM64D 1700 57.0 40.5 16.00 13.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total
electric power input in watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL
CFM RANGE
(MIN.-MAX.)
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
TC7B1821S CF/CM/CU18A 14.5 450 - 750 600 17.8 13.4 15.50 12.75
TC7B1821S CF/CM/CU18B 17.5 450 - 750 600 17.8 13.4 15.50 12.75
TC7B1821S CF/CM/CU24A 14.5 450 - 750 600 18.0 13.5 15.75 12.75
TC7B1821S CF/CM/CU24B 17.5 450 - 750 600 18.0 13.5 15.75 12.75
TC7B1821S CF/CM/CU24C 21 450 - 750 600 18.0 13.5 15.75 12.75
TC7B1821S CF/CM/CU30A 14.5 450 - 750 600 18.0 13.4 16.00 13.00
TC7B1821S CF/CM/CU30B 17.5 450 - 750 600 18.0 13.4 16.00 13.00
TC7B1821S CF/CM/CU30C 21 450 - 750 600 18.0 13.4 16.00 13.00
TC7B1821S CF/CM/CU30D 24.5 450 - 750 600 18.0 13.4 16.00 13.00
TC7B1821S CF/CM/CU36B 17.5 450 - 750 600 18.0 13.5 16.00 13.00
TC7B1821S CF/CM/CU36C 21 450 - 750 600 18.0 13.5 16.00 13.00
TC7B1821S CF/CM/CU36D 24.5 450 - 750 600 18.0 13.5 16.00 13.00
TC7B1821S CF/CM36A 14.5 450 - 750 600 18.0 13.5 16.00 13.00
TC7B2421S CF/CM/CU24A 14.5 600 - 1000 800 23.6 18.0 15.50 12.75
TC7B2421S CF/CM/CU24B 17.5 600 - 1000 800 23.6 18.0 15.50 12.75
TC7B2421S CF/CM/CU24C 21 600 - 1000 800 23.6 18.0 15.50 12.75
TC7B2421S CF/CM/CU30A 14.5 600 - 1000 800 24.0 18.3 15.75 13.00
TC7B2421S CF/CM/CU30B 17.5 600 - 1000 800 24.0 18.3 15.75 13.00
TC7B2421S CF/CM/CU30C 21 600 - 1000 800 24.0 18.3 15.75 13.00
TC7B2421S CF/CM/CU30D 24.5 600 - 1000 800 24.0 18.3 15.75 13.00
TC7B2421S CF/CM/CU36B 17.5 600 - 1000 800 24.0 18.1 16.00 13.00
TC7B2421S CF/CM/CU36C 21 600 - 1000 800 24.0 18.1 16.00 13.00
TC7B2421S CF/CM/CU36D 24.5 600 - 1000 800 24.0 18.1 16.00 13.00
TC7B2421S CF/CM/CU42C 21 600 - 1000 800 24.0 18.0 16.00 13.00
TC7B2421S CF/CM/CU42D 24.5 600 - 1000 800 24.0 18.0 16.00 13.00
TC7B2421S CF/CM36A 14.5 600 - 1000 800 24.0 18.1 16.00 13.00
TC7B2421S CF42B 17.5 600 - 1000 800 24.0 18.0 16.00 13.00
TC7B3021S CF/CM/CU30B 17.5 800 - 1200 1000 28.0 20.4 14.75 12.50
TC7B3021S CF/CM/CU30C 21 800 - 1200 1000 28.0 20.4 14.75 12.50
TC7B3021S CF/CM/CU30D 24.5 800 - 1200 1000 28.0 20.4 14.75 12.50
TC7B3021S CF/CM/CU36B 17.5 800 - 1200 1000 28.4 21.0 15.50 12.75
Continued on next page.
