Luxaire TC7B3021S - Page 35

5186767-LTG-B-0816
Johnson Controls Unitary Products 35
TC7B4221S LPLC080C16MP12 21.0 CF/CM/CU42C 1325 41.0 28.8 16.00 13.00
TC7B4221S LPLC080C16MP12 21.0 CF/CM/CU48C 1325 42.0 29.2 16.25 13.50
TC7B4221S LPLC080C16MP12 21.0 CF/CM/CU48D 1300 42.0 29.0 16.50 13.75
TC7B4221S LPLC080C16MP12 21.0 CF/CM/CU60C 1325 42.0 29.8 16.50 13.75
TC7B4221S LPLC080C16MP12 21.0 CF/CM/CU60D 1325 42.0 29.8 16.50 13.75
TC7B4221S LPLC080C16MP12 21.0 CF/CM64D 1250 42.0 28.8 16.50 13.75
TC7B4221S LPLC100C16MP12 21.0 CF/CM/CU42C 1325 41.0 28.8 16.00 13.00
TC7B4221S LPLC100C16MP12 21.0 CF/CM/CU48C 1325 42.0 29.2 16.25 13.50
TC7B4221S LPLC100C16MP12 21.0 CF/CM/CU48D 1300 42.0 29.0 16.50 13.75
TC7B4221S LPLC100C16MP12 21.0 CF/CM/CU60C 1325 42.0 29.8 16.50 13.75
TC7B4221S LPLC100C16MP12 21.0 CF/CM/CU60D 1325 42.0 29.8 16.50 13.75
TC7B4221S LPLC100C16MP12 21.0 CF/CM64D 1250 42.0 28.8 16.50 13.75
TC7B4221S LPLC100C20MP12 21.0 CF/CM/CU42C 1225 41.0 27.8 16.25 13.25
TC7B4221S LPLC100C20MP12 21.0 CF/CM/CU48C 1250 42.0 28.6 16.50 13.75
TC7B4221S LPLC100C20MP12 21.0 CF/CM/CU48D 1225 41.5 28.2 16.50 13.75
TC7B4221S LPLC100C20MP12 21.0 CF/CM/CU60C 1225 42.0 28.8 16.50 13.75
TC7B4221S LPLC100C20MP12 21.0 CF/CM/CU60D 1225 42.0 28.8 16.50 13.75
TC7B4221S LPLC100C20MP12 21.0 CF/CM64D 1200 41.5 27.8 16.50 13.75
TC7B4221S LPLC120C20MP12 21.0 CF/CM/CU42C 1225 41.0 27.8 16.25 13.25
TC7B4221S LPLC120C20MP12 21.0 CF/CM/CU48C 1250 42.0 28.6 16.50 13.75
TC7B4221S LPLC120C20MP12 21.0 CF/CM/CU48D 1225 41.5 28.2 16.50 13.75
TC7B4221S LPLC120C20MP12 21.0 CF/CM/CU60C 1225 42.0 28.8 16.50 13.75
TC7B4221S LPLC120C20MP12 21.0 CF/CM/CU60D 1225 42.0 28.8 16.50 13.75
TC7B4221S LPLC120C20MP12 21.0 CF/CM64D 1200 41.5 27.8 16.50 13.75
TC7B4821S TM8V080C16MP11 21.0 CF/CM/CU48C 1325 44.5 30.6 15.75 13.00
TC7B4821S TM8V080C16MP11 21.0 CF/CM/CU48D 1300 45.0 30.8 15.75 13.00
TC7B4821S TM8V080C16MP11 21.0 CF/CM/CU60C 1325 45.5 31.6 16.25 13.25
TC7B4821S TM8V080C16MP11 21.0 CF/CM/CU60D 1325 45.5 31.6 16.25 13.50
TC7B4821S TM8V080C16MP11 21.0 CF/CM64D 1400 46.5 33.0 16.25 13.50
TC7B4821S TM8V100C16MP11 21.0 CF/CM/CU48C 1325 44.5 30.6 15.75 13.00
TC7B4821S TM8V100C16MP11 21.0 CF/CM/CU48D 1300 45.0 30.8 15.75 13.00
TC7B4821S TM8V100C16MP11 21.0 CF/CM/CU60C 1325 45.5 31.6 16.25 13.25
TC7B4821S TM8V100C16MP11 21.0 CF/CM/CU60D 1325 45.5 31.6 16.25 13.50
TC7B4821S TM8V100C16MP11 21.0 CF/CM64D 1400 46.5 33.0 16.25 13.50
TC7B4821S TM8V100C20MP11 21.0 CF/CM/CU48C 1300 45.0 30.8 15.75 13.00
TC7B4821S TM8V100C20MP11 21.0 CF/CM/CU48D 1650 45.5 32.8 16.25 13.50
TC7B4821S TM8V100C20MP11 21.0 CF/CM/CU60C 1400 46.0 32.8 16.00 13.25
TC7B4821S TM8V100C20MP11 21.0 CF/CM/CU60D 1350 45.5 31.4 16.00 13.25
TC7B4821S TM8V100C20MP11 21.0 CF/CM64D 1425 47.0 33.4 16.25 13.25
TC7B4821S TM8V120C20MP11 21.0 CF/CM/CU48C 1300 45.0 30.8 15.75 13.00
TC7B4821S TM8V120C20MP11 21.0 CF/CM/CU48D 1650 45.5 32.8 16.25 13.50
TC7B4821S TM8V120C20MP11 21.0 CF/CM/CU60C 1400 46.0 32.8 16.00 13.25
TC7B4821S TM8V120C20MP11 21.0 CF/CM/CU60D 1350 45.5 31.4 16.00 13.25
TC7B4821S TM8V120C20MP11 21.0 CF/CM64D 1425 47.0 33.4 16.25 13.25
TC7B4821S TM8X080C16MP11 21.0 CF/CM/CU48C 1400 45.5 32.0 15.75 13.00
TC7B4821S TM8X080C16MP11 21.0 CF/CM/CU48D 1425 45.5 32.4 15.75 13.00
TC7B4821S TM8X080C16MP11 21.0 CF/CM/CU60C 1400 46.0 32.8 16.00 13.25
TC7B4821S TM8X080C16MP11 21.0 CF/CM/CU60D 1425 46.5 33.0 16.25 13.25
TC7B4821S TM8X080C16MP11 21.0 CF/CM64D 1400 46.5 33.0 16.25 13.50
TC7B4821S TM8X100C16MP11 21.0 CF/CM/CU48C 1400 45.5 32.0 15.75 13.00
TC7B4821S TM8X100C16MP11 21.0 CF/CM/CU48D 1425 45.5 32.4 15.75 13.00
TC7B4821S TM8X100C16MP11 21.0 CF/CM/CU60C 1400 46.0 32.8 16.00 13.25
TC7B4821S TM8X100C16MP11 21.0 CF/CM/CU60D 1425 46.5 33.0 16.25 13.25
Continued on next page.
COOLING CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
