BELT DRIVE ANALOG PLAYER PD-151
MARKⅡ
7
7. Center spindle
This spindle is a center shaft to put a record.
For playing an EP record, mount the EP adaptor (accessory)
here.
8. Motor pulley
This pulley transfers motor rotation to the belt.
9. Belt
This belt transfers motor rotation to the platter.
10. Rubber mat
This rubber mat suppresses platter squeaks and brings a
record into intimate contact with the platter.
11. Headshell
Attach the cartridge to the tone arm.
12. Arm lifter
This lifter moves the cartridge up and down at playback.
13. Anti-skating adjustment knob
This knob cancels an inward force applied to the tone arm
during record playback.
Perform adjustment in accordance with the stylus pressure
of your cartridge.
14. Counter weight
This weight is used to adjust the stylus pressure of your
cartridge.
Top view
