8
Names and Functions
Bottom view
15. Insulators
Support the entire player and absorb howling and vibration
from outside.
These insulators are set at the lowest point at shipment and
can be raised by up to 5 mm.
Use these insulators for making this unit horizontal.
16. Phono cable
This cable is connected to the DIN5P connector of the tone
arm.
(The phono cable is connected to the main unit at ship-
ment.)
17. Cable holder
This holder fixes the phono cable.
