BELT DRIVE ANALOG PLAYER PD-151
9
Rear view
18. AC inlet (AC IN)
Please connect the accessory power cable to supply the
power from the AC outlet on the wall.
19. Hinge support bracket mounting
sections
Mounting sections for an optional dust cover (OPPD-
DSC151).
Screws for mounting of the hinge support bracket are at-
tached.
When not using a dust cover, do not remove the screws.
