Sbach 342 • wingspan: 2,9 m • length: 2,7 m • engine: 100–170 cc • RTF weight: 15–16 kg
7
Rudder
30. Finished rudder before covering of the film29. Glue one edge (CA) and then the rest (dispersion
adhesive)
28. For easy making of arc - water the light balsa 2mm27. Balsa cover on the rudder top
26. Join rudder to fuselage with 4 mm brass tube25. Put the ribs of rudder together and glue
