SIDE BURNER ACCESSORY CARE & USE/INSTALLATION
|
23
outDoor reFriGerators
MODEL A B C D
L24REF 24.25 33.00 26.00 32.00
L24BF 24.25 34.50 26.00 34.25
L24DWR 24.25 34.50 26.00 34.25
L15ICE 15.25 34.00 26.00 33.50
1
1/8
” min. for model LUDE
3
1/2
” min. for model LUDXL
2
1/2
” min. for model LDR (access door)
* Cocktail Pro should have an open bottom for plumbing and drain access.
** 1” square hole must be located at rear of grill cutout. 120V GFI outlet must
be located within 6’ of the 1” hole.
1/2” NPT
gas connection
CLEARANCE
ICE MACHINE
3”
2”Ø or 2” square holes
for manifold connection
(rear or bottom access)
12” min.
Grill**
Cocktail Pro*
Warming Drawer/
Convenience Center
Utility
Drawer
Side
Burner
Drop In
Cooler
(LDC18)
Access
Doors
A
B
2
1/4
”
3
1/2
”
3
1/4
” min.
2”
3” min.
C
Trash
Center
36
3/8
”
min.
3
1/2
”
8
1/4
”
18
1/4
”
6
1/4
”
18
1/4
”
Trash
Chute
(L18TS)
2
3/
16
''
13 ''
Single
Storage Drawer
3”
min.
14
1/2
''
8
1/4
''
Towel
Dispenser
(L16TWL)
A
A
A
A
A
B
B
B
B
A
B
B
A
min.
max.
OUTDOOR REFRIGERATORS
a
e
d
f
c
b
D
B
C
A
D
B
C
A
SPECIFICATIONS & INSTAllATION
