Channel CH (reection)
format LOGMAG
Scale is 10 dB
Current value is .dB
In addition, the channel display is reversed for the active trace.
8. Battery status
If the battery is installed and is D2 already mounted on the PCB , an icon will be displayed according to the battery voltage.
Main screen 2
