d. valve
Fixing the handle
e.Allen bolt M8x110 - 1
piece
k.washer 5 widened for the nuts for
t
plexiglas – 8 pcs
l.plexiglas and beam M5 – 16 pcs
.
e1. handle - 1 piece
e2.f.cap nut M8 - 1
piece
Fixing the lid:
f. front lid made of Plexiglas with five orifices - 1
piece
f1. Rear lid made of Plexiglas with four orifices –
1 piece.
g.
bolt to screw up the handle to
plexiglas – 1 piece
h. grip to lift the
extractor lid – 1 piece
i. lid hinge – 4 pcs
j. screw 4,2x19 – 16 pcs
ASSEMBLING THE HONEY
EXTRACTOR WITH MANUAL DRIVE
1.
Extractor drum with assembled manual
drive shall be taken out of the carton box
2.
Take out the set of assembling elements for
self-assembly
3.
Assembling the legs and valve
4.
Assembling the handle
5.
Assembling the Plexiglas
ASSEMBLING THE HANDLE
e2 e1 e
d. b. a.
Valve assembling Legassembling
