M-Audio Code 49 User Manual

101 ALT 211119106A
CAP SMD CER 1206 10UF 10% 25V X7R "WALSIN" 1206B106K250CT
"ROHS" 0.00
102 ALT 211119106B
CAP SMD CER 1206 10UF 10% 25V X7R "YAGEO" C1206KKX7R8BB106
"ROHS" 0.00
103 213103104
CAP SMD 0603 0.1UF 50V 5% X7R "YAGEO" CC0603JRX7R9BB104
"ROHS" 8.00 EA
104 213119016 CAP SMD 0603 CER 1UF 10% 25V X7R "ROHS" 19.00 EA
105 311101812 IC SMD SOP-16 "TITAN MICRO" TM1812 "ROHS" 4.00 EA
106 311574405B
ANALOG MULTIPLEXER/DEMULTIPLEXER SINGLE 8-CHANNEL
SO16_N "NXP" 74HC4051 "ROHS" 2.00 EA
107 320181033 IC SMD PROGRAMMED TSSOP20 "ST" STM8S103F3P6TR "ROHS" 1.00 EA
108 310181033 IC SMD TSSOP20 "ST" STM8S103F3P6TR "ROHS" 1.00 EA
109 461990190 LED SMD D0605 "JASIONAL" JX-SP190URGBCB "ROHS" 32.00 EA
110 ALT 461990190A LED SMD 0606 "HONGBRIGHT" H-0606AUGB0108-02 "ROHS" 0.00
111 ALT 461990190B LED SMD 0605 "TIAN DE XIANG" TKS16-1555URUBGSURC "ROHS" 0.00
112 711648500
CONNECTOR FPC SMD 10PIN P=1.0mm "SHENGPIN" ML1.0-2L-10PB
"ROHS" 2.00 EA
113 105-MK42-53 PCB SMD ASSY LEDBOARD MK42 "ROHS" 4.00 EA
114 023496001 PCB FR4 1.2mm 1L 1OZ 25.7*7mm REV:0.05 FOR LEDBOARD "ROHS" 4.00 EA
115 411380000
LED SMD 0603 HIGH-BRIGHTNESS AMBER MAX 30MA "HERON" INH-
S1608BHO05TP-C "ROHS" 11.00 EA
116 105-MK42-62 PCB ASSY JACK BOARD FOR MK42 "ROHS" 1.00 EA
117 023558101
PCB FR4 1.6mm 2L 142.2*31.5mm REV:0.5 JACK BOARD FOR MK42
"ROHS" 1.00 EA
118 061558001
CABLE UL2464 26AWG 12PIN P=2.54mm L=200mm SHIELD
FEMALE＆MALE "GUANLI" GL-201411111001Q "ROHS" 1.00 EA
119 412585819
DIODE DO-41 SCHOTTKY 1 AMP 40 PIV T&R "FAIRCHILD" 1N5819
"ROHS" 1.00 EA
120 ALT 412585819B DIODE DO-41 SCHOTTKY 1 AMP 40 PIV "DIODES" 1N5819-T "ROHS" 0.00
121 612153000 SWITCH TOGGLE DPTT 3POS 8PIN "HAOYU" PS-22F02-N-B "ROHS" 1.00 EA
122 722539903 USB JACK B-TYPE WHITE "HAOYU" USB-109(WHITE) "ROHS" 1.00 EA
123 ALT 722539903B USB JACK B-TYPE WHITE "CHUANGXIANG" HW-UBF-01 "ROHS" 0.00
124 722569902 MIDI JACK 7PIN BLACK "CHUANGXIANG" DIN-D503 "ROHS" 2.00 EA
125 722609901A JACK DC POWER 2.0 "HAOYU" DC-005(Φ2.0) "ROHS" 1.00 EA
126 722805800 PHONE JACK 4PIN 6.35mm "HAOYU" PJ-603A "ROHS" 2.00 EA
127 105-MK43-61 PCB ASSY MAINBOARD FOR MK43 "ROHS" 1.00 EA
128 022558000 RUBBER 20.6*7*3.5mm REV:0.5 "ROHS" 3.00 EA
129 073558000 DISPLAY AMBER LED "TIANDEXIANG" TKY5341AAW "ROHS" 2.00 EA
130 ALT 073558000A DISPLAY AMBER LED "JASIONAL" JX5341AO "ROHS" 0.00
131 105-MK43-51 PCB SMD ASSY MAINBOARD FOR MK43 "ROHS" 1.00 EA
132 023559002 PCB FR4 1.6mm 2L 454.5*70.5mm REV:0.8 MAINBOARD MK43 "ROHS" 1.00 EA
133 111330000 RES SMD 1206 1/8W 5% 0R "ROHS" 1.00 EA
134 113006000 FERRITE BEAD SMD 0603 600R "FENGHUA" CBG160808U601T "ROHS" 10.00 EA
135 113111001 RES SMD 0603 1/16W 1% 1K "ROHS" 5.00 EA
136 113111004 RES SMD 0603 1/16W 1% 1M T&R "FENG HUA" "ROHS" 1.00 EA
137 113130000B RES SMD 0603 1/16W 5% 0R "YAGEO" RC0603JR-070R "ROHS" 50.00 EA
138 113130220 RES SMD 0603 1/16W 5% 22R "ROHS" 2.00 EA
139 113132200 RES SMD 0603 1/16W 5% 220R "ROHS" 1.00 EA
140 113135102 RES SMD 0603 1/16W 5% 51K "ROHS" 1.00 EA
141 113211000 RES SMD 0603 1/8W 1% 100R T&R "FENGHUA" RS-03K1000FT "ROHS" 4.00 EA
142 113211003 RES SMD 0603 1/10W 1% 100K "FENGHUA" RS-03K1003FT "ROHS" 2.00 EA

M-Audio Code 49 Specifications

General

MIDI-keyboard number of keys	49 keys
Product color	White
Pitch bend wheel	Yes
Interface	USB
Power source type	-
